Test Date: 2016-09-14 10:46
Analysis date: 2016-10-06 11:53
Analysis date: 2016-10-06 11:53
M-P-5-43 XRayHRQualification
Summary
| Module | Module | M-P-5-43 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 248 | |
| BumpBondingDefects | Bump Bonding Defects | 248 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.82/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
28 | 99.96 | 99.88 | 99.65 | 0.12 | 17.9 | 60.1 | 28 | 0/0 | 0 |
|
Chip 1
|
A
|
21 | 99.96 | 99.88 | 99.60 | 0.09 | 12.3 | 41.7 | 21 | 0/0 | 0 |
|
Chip 2
|
A
|
17 | 99.96 | 99.89 | 99.64 | 0.09 | 18.3 | 61.8 | 17 | 0/0 | 0 |
|
Chip 3
|
A
|
19 | 99.95 | 99.90 | 99.72 | 0.16 | 28.7 | 96.7 | 19 | 0/0 | 0 |
|
Chip 4
|
A
|
24 | 99.96 | 99.88 | 99.61 | 0.18 | 30.9 | 104.1 | 24 | 0/0 | 0 |
|
Chip 5
|
A
|
50 | 99.94 | 99.85 | 99.56 | 0.14 | 31.4 | 105.7 | 50 | 0/0 | 0 |
|
Chip 6
|
A
|
34 | 99.95 | 99.87 | 99.61 | 0.15 | 31.7 | 106.5 | 34 | 0/0 | 0 |
|
Chip 7
|
A
|
5 | 99.94 | 99.87 | 99.63 | 0.14 | 21.6 | 73.0 | 5 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.94 | 99.85 | 99.53 | 0.73 | 20.8 | 70.0 | 1 | 0/0 | 0 |
|
Chip 9
|
A
|
2 | 99.95 | 99.87 | 99.61 | 0.18 | 27.8 | 93.5 | 2 | 0/0 | 0 |
|
Chip 10
|
A
|
1 | 99.95 | 99.88 | 99.62 | 0.14 | 27.2 | 91.8 | 1 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.95 | 99.90 | 99.71 | 0.09 | 24.0 | 81.1 | 1 | 0/0 | 0 |
|
Chip 12
|
A
|
3 | 99.95 | 99.88 | 99.64 | 0.14 | 24.6 | 83.0 | 3 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.96 | 99.90 | 99.71 | 0.07 | 14.9 | 50.2 | 13 | 0/0 | 0 |
|
Chip 14
|
A
|
29 | 99.94 | 99.13 | -1.00 | 0.03 | 6.3 | 21.4 | 29 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.64 | -1.00 | 0.02 | 7.5 | 25.5 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 468 | |
| nWarnings | # Warnings | 9 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 52 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 52 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
