M-P-5-07 XRayHRQualification
Summary
| Module | Module | M-P-5-07 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 7/1/8 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 8 | |
| Efficiency | Efficiency 20/50/80 | 99.14/99.08/98.74 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
0 | 98.91 | 98.91 | 98.91 | 42.74 | 17.9 | 38.4 | 0 | 0/0 | 1 |
|
Chip 1
|
C
|
0 | 99.39 | 99.39 | 99.39 | 10.77 | 11.2 | 25.6 | 0 | 0/0 | 1 |
|
Chip 2
|
C
|
0 | 99.28 | 99.15 | 98.73 | 12.68 | 18.7 | 42.9 | 0 | 0/0 | 1 |
|
Chip 3
|
A
|
0 | 99.00 | 99.00 | 99.00 | 6.99 | 27.5 | 63.8 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.01 | 99.01 | 99.01 | 6.08 | 28.4 | 66.4 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 98.86 | 98.86 | 98.86 | 9.27 | 29.8 | 67.8 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 100.00 | 99.94 | 99.74 | 0.00 | 37.6 | 74.9 | 0 | 0/0 | 0 |
|
Chip 7
|
C
|
0 | 98.77 | 98.45 | 97.41 | 35.72 | 29.2 | 66.0 | 0 | 0/0 | 1 |
|
Chip 8
|
C
|
0 | 100.94 | 100.06 | 97.17 | 13.33 | 36.0 | 74.9 | 0 | 0/0 | 2 |
|
Chip 9
|
B
|
0 | 99.16 | 98.84 | 97.77 | 41.80 | 32.8 | 73.4 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 98.95 | 98.95 | 98.95 | 17.23 | 30.4 | 69.7 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.26 | 99.26 | 99.26 | 3.20 | 27.5 | 63.7 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.19 | 99.19 | 99.19 | 3.63 | 27.6 | 64.4 | 0 | 0/0 | 0 |
|
Chip 13
|
C
|
0 | 99.39 | 99.29 | 98.97 | 3.99 | 18.7 | 43.1 | 0 | 0/0 | 1 |
|
Chip 14
|
C
|
0 | 98.50 | 98.50 | -1.00 | 11.64 | 12.3 | 27.3 | 0 | 0/0 | 3 |
|
Chip 15
|
C
|
3 | 99.40 | 99.40 | -1.00 | 0.88 | 15.6 | 33.3 | 3 | 0/0 | 3 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 2472 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 758 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 758 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
