M-P-4-46 XRayHRQualification
Summary
| Module | Module | M-P-4-46 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 337 | |
| BumpBondingDefects | Bump Bonding Defects | 337 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.82/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.84 | 99.45 | 0.14 | 26.2 | 0 | 7.9 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.96 | 99.87 | 99.60 | 0.10 | 22.9 | 0 | 6.9 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.09 | 37.3 | 0 | 11.3 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.88 | 99.69 | 0.14 | 55.5 | 0 | 16.9 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.92 | 99.87 | 99.74 | 0.17 | 60.7 | 0 | 18.5 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.89 | 99.67 | 0.19 | 61.3 | 0 | 18.7 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.92 | 99.88 | 99.73 | 0.12 | 60.9 | 0 | 18.6 | 0/0 | 0 |
|
Chip 7
|
A
|
27 | 99.88 | 99.84 | 99.72 | 1.19 | 56.6 | 27 | 17.4 | 0/0 | 0 |
|
Chip 8
|
C
|
187 | 99.99 | 99.83 | 99.34 | 0.43 | 66.3 | 187 | 25.3 | 0/0 | 1 |
|
Chip 9
|
A
|
69 | 99.87 | 99.78 | 99.50 | 5.00 | 65.1 | 69 | 20.9 | 0/0 | 0 |
|
Chip 10
|
A
|
51 | 99.92 | 99.86 | 99.65 | 0.21 | 64.5 | 51 | 19.7 | 0/0 | 0 |
|
Chip 11
|
A
|
3 | 99.92 | 99.87 | 99.68 | 1.12 | 60.9 | 3 | 18.6 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.12 | 58.3 | 0 | 17.8 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.17 | 37.6 | 0 | 11.4 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.95 | 99.47 | -1.00 | 0.06 | 22.5 | 0 | 6.8 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.50 | -1.00 | 0.02 | 22.7 | 0 | 6.9 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
