Test Date: 2016-06-23 12:35
Analysis date: 2016-06-24 13:42
Analysis date: 2016-06-24 13:42
M-P-4-03 XRayHRQualification
Summary
| Module | Module | M-P-4-03 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 12/0/4 | |
| PixelDefects | Total Pixel Defects | 536 | |
| BumpBondingDefects | Bump Bonding Defects | 536 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 4 | |
| Efficiency | Efficiency 20/50/80 | 99.93/99.70/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
191 | 99.93 | 99.85 | 99.59 | 0.76 | 54.0 | 191 | 27.9 | 0/0 | 1 |
|
Chip 1
|
C
|
106 | 99.85 | 99.80 | 99.63 | 1.30 | 47.9 | 106 | 25.4 | 0/0 | 16 |
|
Chip 2
|
C
|
62 | 99.96 | 99.90 | 99.70 | 0.09 | 47.8 | 62 | 15.0 | 0/0 | 3 |
|
Chip 3
|
A
|
50 | 99.85 | 99.78 | 99.53 | 7.48 | 81.4 | 50 | 25.5 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.94 | 99.89 | 99.74 | 0.42 | 92.6 | 1 | 29.0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.20 | 98.1 | 0 | 30.7 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.89 | 99.66 | 0.10 | 89.1 | 0 | 27.8 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.89 | 99.66 | 0.11 | 67.9 | 0 | 21.1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.12 | 65.8 | 0 | 20.5 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.14 | 83.1 | 0 | 25.9 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.17 | 82.1 | 0 | 25.6 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.14 | 70.6 | 0 | 22.0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.87 | 99.59 | 0.07 | 76.7 | 0 | 23.9 | 0/0 | 0 |
|
Chip 13
|
A
|
19 | 99.95 | 99.88 | 99.65 | 0.14 | 44.2 | 19 | 13.8 | 0/0 | 0 |
|
Chip 14
|
A
|
36 | 99.93 | 99.04 | -1.00 | 0.02 | 17.8 | 36 | 5.5 | 0/0 | 0 |
|
Chip 15
|
C
|
71 | 99.76 | 97.97 | -1.00 | 6.14 | 19.1 | 71 | 6.2 | 0/0 | 2 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 25 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
