M-P-3-37 XRayHRQualification
Summary
| Module | Module | M-P-3-37 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 7/1/8 | |
| PixelDefects | Total Pixel Defects | 1185 | |
| BumpBondingDefects | Bump Bonding Defects | 1185 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 3 | |
| Efficiency | Efficiency 20/50/80 | 94.46/99.02/95.72 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
130 | 99.83 | 97.22 | 88.60 | 0.01 | 2.8 | 8.5 | 130 | 0/0 | 0+2/0 |
|
Chip 1
|
A
|
107 | 99.97 | 99.85 | 99.46 | 0.00 | 1.8 | 5.6 | 107 | 0/0 | 0 |
|
Chip 2
|
A
|
50 | 99.99 | 99.99 | 99.99 | 0.02 | 2.1 | 6.5 | 50 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.98 | 99.98 | 99.98 | 0.02 | 3.7 | 11.4 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.56 | 98.26 | 0.04 | 3.8 | 11.7 | 0 | 0/0 | 0 |
|
Chip 5
|
B
|
0 | 99.96 | 99.36 | 97.37 | 0.03 | 4.8 | 14.6 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.55 | 98.21 | 0.03 | 5.5 | 17.1 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
10 | 99.96 | 99.65 | 98.62 | 0.03 | 5.3 | 16.3 | 10 | 0/0 | 0 |
|
Chip 8
|
C
|
183 | 99.94 | 99.28 | 97.10 | 0.05 | 3.9 | 12.1 | 183 | 0/0 | 0+2/0 |
|
Chip 9
|
C
|
68 | 92.45 | -32.66 | -446.46 | 4.77 | 2.7 | 8.4 | 68 | 0/0 | 0 |
|
Chip 10
|
A
|
33 | 99.97 | 99.69 | 98.79 | 0.07 | 3.8 | 11.7 | 33 | 0/0 | 0 |
|
Chip 11
|
C
|
12 | 99.78 | 96.81 | 86.98 | 3.41 | 4.0 | 12.2 | 12 | 0/0 | 0 |
|
Chip 12
|
C
|
52 | 99.91 | 98.74 | 94.85 | 0.02 | 3.4 | 10.6 | 52 | 0/0 | 0 |
|
Chip 13
|
C
|
115 | 99.80 | 96.64 | 86.19 | 0.12 | 1.8 | 5.7 | 115 | 0/0 | 0 |
|
Chip 14
|
C
|
220 | 19.98 | -1150.02 | -1.00 | 3.75 | 0.9 | 2.8 | 220 | 0/0 | 0 |
|
Chip 15
|
C
|
205 | 99.96 | 99.96 | -1.00 | 2.97 | 1.3 | 4.1 | 205 | 0/0 | 1 |
Errors
| nCriticals | # Criticals | 2 | |
| nErrors | # Errors | 65 | |
| nWarnings | # Warnings | 8 | |
| channel_0_count | Channel 0 | 6 | |
| channel_1_count | Channel 1 | 11 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 4 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_readback_count | Readback start marker | 8 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 1 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
