M-P-2-28 XRayHRQualification
Summary
| Module | Module | M-P-2-28 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 100 | |
| BumpBondingDefects | Bump Bonding Defects | 100 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.79/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.55 | 0.12 | 18.8 | 62.0 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
28 | 99.94 | 99.87 | 99.63 | 0.36 | 11.5 | 38.0 | 28 | 0/0 | 0 |
|
Chip 2
|
A
|
10 | 99.96 | 99.88 | 99.61 | 0.14 | 17.7 | 58.2 | 10 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.87 | 99.65 | 0.15 | 29.0 | 95.4 | 0 | 0/0 | 0 |
|
Chip 4
|
C
|
0 | 99.95 | 99.88 | 99.67 | 0.17 | 29.9 | 96.7 | 0 | 0/0 | 2 |
|
Chip 5
|
A
|
2 | 99.96 | 99.88 | 99.62 | 0.13 | 31.3 | 102.8 | 2 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.11 | 31.7 | 104.2 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.88 | 99.63 | 0.11 | 23.0 | 76.0 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.85 | 99.52 | 0.14 | 21.3 | 70.4 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.88 | 99.64 | 0.13 | 27.0 | 88.6 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.20 | 27.1 | 89.0 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.12 | 22.3 | 73.4 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.89 | 99.70 | 0.09 | 23.3 | 76.8 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
10 | 99.95 | 99.88 | 99.65 | 0.15 | 13.7 | 45.3 | 10 | 0/0 | 0 |
|
Chip 14
|
A
|
50 | 99.93 | 99.06 | -1.00 | 0.02 | 5.7 | 18.8 | 50 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.29 | -1.00 | 0.04 | 6.2 | 20.5 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 1 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
