Test Date: 2016-07-29 10:53
Analysis date: 2016-08-03 12:52
Analysis date: 2016-08-03 12:52
M-P-2-20 XRayHRQualification
Summary
| Module | Module | M-P-2-20 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 272 | |
| BumpBondingDefects | Bump Bonding Defects | 272 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.82/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.87 | 99.57 | 0.09 | 17.2 | 52.7 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
28 | 99.96 | 99.88 | 99.61 | 0.10 | 11.4 | 35.0 | 28 | 0/0 | 0 |
|
Chip 2
|
A
|
10 | 99.96 | 99.91 | 99.73 | 0.10 | 18.6 | 57.1 | 10 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.15 | 28.3 | 86.9 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.11 | 31.0 | 95.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.08 | 30.4 | 92.9 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.75 | 0.11 | 30.2 | 92.5 | 0 | 0/0 | 0 |
|
Chip 7
|
C
|
160 | 99.95 | 99.88 | 99.64 | 0.11 | 18.3 | 56.1 | 160 | 0/0 | 2 |
|
Chip 8
|
A
|
0 | 99.97 | 99.90 | 99.68 | 0.10 | 18.1 | 55.7 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
3 | 99.96 | 99.89 | 99.68 | 0.11 | 26.3 | 81.0 | 3 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.90 | 99.73 | 0.12 | 25.2 | 77.6 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.13 | 21.1 | 65.1 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.10 | 21.3 | 65.5 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
17 | 99.95 | 99.86 | 99.57 | 0.16 | 12.9 | 39.9 | 17 | 0/0 | 0 |
|
Chip 14
|
A
|
54 | 99.96 | 99.42 | -1.00 | 0.01 | 5.3 | 16.5 | 54 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.38 | -1.00 | 0.03 | 6.7 | 20.7 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 26 | |
| nWarnings | # Warnings | 24 | |
| channel_0_count | Channel 0 | 1 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-904-gd94b9f2 on branch master
