Test Date: 2016-08-11 12:15
Analysis date: 2016-08-14 21:52
Analysis date: 2016-08-14 21:52
M-P-2-07 XRayHRQualification
Summary
| Module | Module | M-P-2-07 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 180 | |
| BumpBondingDefects | Bump Bonding Defects | 180 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.51 | 0.14 | 46.4 | 0 | 15.0 | 0/0 | 0 |
|
Chip 1
|
A
|
28 | 99.97 | 99.86 | 99.50 | 0.05 | 30.0 | 28 | 9.7 | 0/0 | 0 |
|
Chip 2
|
A
|
8 | 99.96 | 99.90 | 99.67 | 0.10 | 46.7 | 8 | 15.1 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.21 | 71.4 | 0 | 23.1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.08 | 80.4 | 0 | 25.9 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.11 | 83.2 | 0 | 26.9 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.95 | 99.91 | 99.74 | 0.10 | 81.0 | 1 | 26.2 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.90 | 99.68 | 0.13 | 59.3 | 0 | 19.1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.88 | 99.59 | 0.18 | 53.7 | 0 | 17.3 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.91 | 99.75 | 0.10 | 62.3 | 0 | 20.1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.97 | 99.90 | 99.67 | 0.08 | 67.9 | 0 | 21.9 | 0/0 | 0 |
|
Chip 11
|
A
|
64 | 99.97 | 99.90 | 99.67 | 0.11 | 56.1 | 64 | 18.1 | 0/0 | 0 |
|
Chip 12
|
A
|
2 | 99.96 | 99.89 | 99.66 | 0.14 | 59.3 | 2 | 19.1 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.96 | 99.88 | 99.63 | 0.08 | 35.6 | 9 | 11.5 | 0/0 | 0 |
|
Chip 14
|
A
|
68 | 99.96 | 99.40 | -1.00 | 0.01 | 13.7 | 68 | 4.4 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.36 | -1.00 | 0.03 | 17.5 | 0 | 5.6 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
