Test Date: 2016-08-05 10:18
Analysis date: 2016-12-28 12:48
Analysis date: 2016-12-28 12:48
M-O-3-50 XRayHRQualification
Summary
| Module | Module | M-O-3-50 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 236 | |
| BumpBondingDefects | Bump Bonding Defects | 236 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.86/99.68 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
4 | 99.95 | 99.86 | 99.57 | 0.27 | 61.1 | 4 | 18.9 | 0/0 | 0 |
|
Chip 1
|
A
|
18 | 99.97 | 99.87 | 99.54 | 0.06 | 39.8 | 18 | 12.3 | 0/0 | 0 |
|
Chip 2
|
A
|
8 | 99.95 | 99.88 | 99.65 | 0.09 | 64.6 | 8 | 20.0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.11 | 103.3 | 0 | 32.1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.13 | 104.7 | 0 | 32.5 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.19 | 103.5 | 0 | 32.1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.88 | 99.64 | 0.13 | 106.4 | 0 | 33.1 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.08 | 84.5 | 0 | 26.2 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.13 | 72.8 | 0 | 22.5 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.20 | 87.9 | 0 | 27.2 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.16 | 86.1 | 0 | 26.7 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.95 | 99.91 | 99.78 | 0.11 | 74.2 | 1 | 23.0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.13 | 76.9 | 0 | 23.8 | 0/0 | 0 |
|
Chip 13
|
A
|
12 | 99.95 | 99.90 | 99.75 | 0.09 | 49.3 | 12 | 15.3 | 0/0 | 0 |
|
Chip 14
|
C
|
193 | 99.96 | 99.62 | -1.00 | 0.03 | 19.7 | 193 | 6.1 | 0/0 | 2 |
|
Chip 15
|
A
|
0 | 99.97 | 99.69 | -1.00 | 0.03 | 24.5 | 0 | 7.6 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
