Test Date: 2016-05-13 13:54
Analysis date: 2016-05-21 20:03
Analysis date: 2016-05-21 20:03
M-O-2-07 XRayHRQualification
Summary
| Module | Module | M-O-2-07 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 90 | |
| BumpBondingDefects | Bump Bonding Defects | 90 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.86/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
7 | 99.96 | 99.88 | 99.62 | 0.10 | 63.8 | 7 | 20.0 | 0/0 | 0 |
|
Chip 1
|
A
|
17 | 99.96 | 99.87 | 99.57 | 0.12 | 43.2 | 17 | 13.5 | 0/0 | 0 |
|
Chip 2
|
A
|
7 | 99.94 | 99.88 | 99.67 | 0.15 | 62.9 | 7 | 19.7 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.89 | 99.65 | 0.13 | 98.2 | 0 | 30.8 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.08 | 106.0 | 0 | 33.3 | 0/0 | 0 |
|
Chip 5
|
A
|
3 | 99.95 | 99.87 | 99.60 | 0.14 | 103.5 | 3 | 32.6 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.94 | 99.90 | 99.77 | 0.09 | 103.3 | 1 | 32.5 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.95 | 99.87 | 99.62 | 0.14 | 73.4 | 1 | 23.0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.94 | 99.88 | 99.67 | 0.10 | 75.9 | 0 | 23.8 | 0/0 | 0 |
|
Chip 9
|
A
|
21 | 99.95 | 99.90 | 99.75 | 0.10 | 94.2 | 21 | 29.6 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.13 | 92.1 | 0 | 29.0 | 0/0 | 0 |
|
Chip 11
|
A
|
2 | 99.95 | 99.90 | 99.74 | 0.12 | 84.1 | 2 | 26.4 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.96 | 99.90 | 99.69 | 0.09 | 83.1 | 1 | 26.1 | 0/0 | 0 |
|
Chip 13
|
A
|
6 | 99.95 | 99.87 | 99.63 | 0.15 | 47.3 | 6 | 14.8 | 0/0 | 0 |
|
Chip 14
|
A
|
24 | 99.96 | 99.56 | -1.00 | 0.02 | 22.2 | 24 | 7.0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.78 | -1.00 | 0.01 | 23.5 | 0 | 7.4 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 62 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
