Test Date: 2016-05-20 14:30
Analysis date: 2016-05-27 13:02
Analysis date: 2016-05-27 13:02
M-O-1-15 XRayHRQualification
Summary
| Module | Module | M-O-1-15 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 76 | |
| BumpBondingDefects | Bump Bonding Defects | 76 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.66/99.55/99.33 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.87 | 99.55 | 0.12 | 18.9 | 58.1 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
18 | 99.97 | 99.88 | 99.59 | 0.11 | 13.2 | 40.4 | 18 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.96 | 99.93 | 99.80 | 0.07 | 19.4 | 59.7 | 5 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.14 | 30.1 | 92.2 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.89 | 99.68 | 0.11 | 32.6 | 99.9 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.94 | 99.87 | 99.64 | 0.16 | 33.6 | 102.9 | 1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.87 | 99.63 | 0.15 | 32.8 | 100.3 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.12 | 25.3 | 77.8 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.91 | 99.74 | 0.11 | 24.0 | 73.7 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.88 | 99.67 | 0.17 | 27.5 | 84.2 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.11 | 27.9 | 85.5 | 0 | 0/0 | 0 |
|
Chip 11
|
C
|
5 | 95.13 | 95.13 | 95.13 | 42563.03 | 24.4 | 74.5 | 5 | 0/0 | 2 |
|
Chip 12
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.12 | 25.2 | 77.3 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.96 | 99.87 | 99.60 | 0.14 | 14.4 | 44.5 | 8 | 0/0 | 0 |
|
Chip 14
|
A
|
39 | 99.96 | 99.52 | -1.00 | 0.01 | 6.3 | 19.3 | 39 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.56 | -1.00 | 0.03 | 6.8 | 21.1 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
