Test Date: 2016-05-11 10:13
Analysis date: 2016-05-22 07:22
Analysis date: 2016-05-22 07:22
M-N-3-48 XRayHRQualification
Summary
| Module | Module | M-N-3-48 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 554 | |
| BumpBondingDefects | Bump Bonding Defects | 554 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.68 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
2 | 99.97 | 99.88 | 99.61 | 0.07 | 18.5 | 60.0 | 2 | 0/0 | 0 |
|
Chip 1
|
A
|
18 | 99.97 | 99.91 | 99.73 | 0.09 | 11.7 | 37.9 | 18 | 0/0 | 0 |
|
Chip 2
|
A
|
5 | 99.96 | 99.90 | 99.71 | 0.10 | 18.5 | 60.0 | 5 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.73 | 0.12 | 28.9 | 93.7 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.10 | 31.6 | 102.3 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.07 | 31.5 | 101.7 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.91 | 99.74 | 0.08 | 33.0 | 106.6 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
262 | 99.96 | 99.89 | 99.66 | 0.11 | 21.5 | 69.8 | 262 | 0/0 | 0 |
|
Chip 8
|
A
|
216 | 99.95 | 99.88 | 99.63 | 0.14 | 20.6 | 67.1 | 216 | 0/0 | 0 |
|
Chip 9
|
A
|
20 | 99.96 | 99.90 | 99.70 | 0.12 | 25.8 | 83.7 | 20 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.10 | 25.7 | 83.4 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.11 | 21.9 | 71.0 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.87 | 99.61 | 0.17 | 23.2 | 75.5 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
5 | 99.97 | 99.92 | 99.75 | 0.09 | 13.6 | 44.0 | 5 | 0/0 | 0 |
|
Chip 14
|
A
|
26 | 99.94 | 99.08 | -1.00 | 0.02 | 6.1 | 19.9 | 26 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.64 | -1.00 | 0.02 | 6.7 | 21.9 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 218 | |
| nWarnings | # Warnings | 4 | |
| channel_0_count | Channel 0 | 17 | |
| channel_1_count | Channel 1 | 13 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 15 | |
| message_eventid_count | Event ID mismatch | 8 | |
| message_readback_count | Readback start marker | 4 | |
| message_notokenpass_count | has NoTokenPass | 3 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
