M-N-3-17 XRayHRQualification
Summary
| Module | Module | M-N-3-17 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 240 | |
| BumpBondingDefects | Bump Bonding Defects | 240 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.97 | 99.90 | 99.66 | 0.06 | 19.6 | 62.1 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
26 | 99.96 | 99.88 | 99.62 | 0.09 | 13.3 | 42.1 | 26 | 0/0 | 0 |
|
Chip 2
|
A
|
4 | 99.96 | 99.91 | 99.72 | 0.06 | 19.7 | 62.4 | 4 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.95 | 99.90 | 99.74 | 0.10 | 31.0 | 98.2 | 1 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.90 | 99.72 | 0.10 | 33.5 | 106.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.96 | 99.90 | 99.72 | 0.17 | 33.5 | 105.8 | 1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.89 | 99.65 | 0.19 | 33.5 | 105.6 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.23 | 27.4 | 86.8 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.15 | 24.7 | 78.1 | 0 | 0/0 | 0 |
|
Chip 9
|
C
|
160 | 99.95 | 99.88 | 99.63 | 0.18 | 28.1 | 88.8 | 160 | 0/0 | 2 |
|
Chip 10
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.16 | 28.6 | 90.5 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.19 | 23.2 | 73.6 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
4 | 99.96 | 99.87 | 99.58 | 0.12 | 24.4 | 77.4 | 4 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.95 | 99.88 | 99.65 | 0.12 | 15.6 | 49.6 | 8 | 0/0 | 0 |
|
Chip 14
|
A
|
36 | 99.95 | 99.28 | -1.00 | 0.01 | 7.1 | 22.6 | 36 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.51 | -1.00 | 0.03 | 8.9 | 28.4 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
