Test Date: 2016-05-27 10:11
Analysis date: 2016-06-09 18:23
Analysis date: 2016-06-09 18:23
M-N-3-05 XRayHRQualification
Summary
| Module | Module | M-N-3-05 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 232 | |
| BumpBondingDefects | Bump Bonding Defects | 232 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.84/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.88 | 99.64 | 0.12 | 50.0 | 0 | 15.4 | 0/0 | 0 |
|
Chip 1
|
A
|
34 | 99.97 | 99.91 | 99.70 | 0.05 | 31.8 | 34 | 9.8 | 0/0 | 0 |
|
Chip 2
|
A
|
9 | 99.96 | 99.88 | 99.60 | 0.12 | 47.4 | 9 | 14.6 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.95 | 99.87 | 99.59 | 0.11 | 79.7 | 1 | 24.5 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.96 | 99.91 | 99.74 | 0.10 | 89.6 | 1 | 27.6 | 0/0 | 0 |
|
Chip 5
|
C
|
0 | 99.63 | 99.63 | 99.63 | 296.28 | 89.8 | 0 | 27.8 | 0/0 | 1 |
|
Chip 6
|
C
|
107 | 99.95 | 99.88 | 99.64 | 0.17 | 90.5 | 107 | 27.9 | 0/0 | 2 |
|
Chip 7
|
A
|
0 | 99.96 | 99.90 | 99.68 | 0.09 | 69.4 | 0 | 21.3 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.96 | 99.90 | 99.68 | 0.15 | 63.7 | 1 | 19.5 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.87 | 99.56 | 0.22 | 80.7 | 0 | 24.8 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.88 | 99.62 | 0.11 | 77.8 | 0 | 23.9 | 0/0 | 0 |
|
Chip 11
|
A
|
4 | 99.95 | 99.87 | 99.59 | 0.35 | 65.4 | 4 | 20.1 | 0/0 | 0 |
|
Chip 12
|
A
|
3 | 99.95 | 99.87 | 99.60 | 0.14 | 70.5 | 3 | 21.7 | 0/0 | 0 |
|
Chip 13
|
A
|
26 | 99.96 | 99.90 | 99.70 | 0.14 | 39.9 | 26 | 12.2 | 0/0 | 0 |
|
Chip 14
|
A
|
45 | 99.96 | 99.53 | -1.00 | 0.02 | 18.0 | 45 | 5.5 | 0/0 | 0 |
|
Chip 15
|
A
|
1 | 99.97 | 99.68 | -1.00 | 0.03 | 20.5 | 1 | 6.3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 915 | |
| nWarnings | # Warnings | 112 | |
| channel_0_count | Channel 0 | 153 | |
| channel_1_count | Channel 1 | 9 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 23 | |
| message_eventid_count | Event ID mismatch | 22 | |
| message_readback_count | Readback start marker | 112 | |
| message_notokenpass_count | has NoTokenPass | 5 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
