Test Date: 2016-04-15 12:29
Analysis date: 2016-05-23 15:12
Analysis date: 2016-05-23 15:12
M-M-4-03 XRayHRQualification
Summary
| Module | Module | M-M-4-03 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 61 | |
| BumpBondingDefects | Bump Bonding Defects | 61 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.80/99.62 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.11 | 17.4 | 59.0 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
11 | 99.97 | 99.88 | 99.60 | 0.12 | 11.9 | 40.4 | 11 | 0/0 | 0 |
|
Chip 2
|
A
|
18 | 99.96 | 99.88 | 99.62 | 0.11 | 18.6 | 62.9 | 18 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.86 | 99.57 | 0.20 | 30.0 | 101.3 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.86 | 99.58 | 0.30 | 30.5 | 102.8 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.08 | 30.8 | 103.7 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.89 | 99.72 | 0.14 | 30.7 | 103.8 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.08 | 22.2 | 75.1 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.94 | 99.87 | 99.64 | 0.17 | 21.0 | 71.1 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.20 | 24.9 | 84.2 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.93 | 99.86 | 99.63 | 0.17 | 26.1 | 88.1 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.89 | 99.65 | 0.11 | 22.4 | 75.8 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.86 | 99.53 | 0.15 | 23.5 | 79.6 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
11 | 99.94 | 99.85 | 99.56 | 0.12 | 14.2 | 48.0 | 11 | 0/0 | 0 |
|
Chip 14
|
A
|
21 | 99.94 | 99.21 | -1.00 | 0.02 | 6.1 | 20.6 | 21 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.94 | 99.38 | -1.00 | 0.04 | 7.1 | 24.3 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 12 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
