Test Date: 2016-05-26 12:04
Analysis date: 2016-06-03 18:57
Analysis date: 2016-06-03 18:57
M-M-2-39 XRayHRQualification
Summary
| Module | Module | M-M-2-39 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 99 | |
| BumpBondingDefects | Bump Bonding Defects | 99 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.75/99.63/99.46 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 99.96 | 99.88 | 99.63 | 0.10 | 60.1 | 3 | 19.1 | 0/0 | 0 |
|
Chip 1
|
C
|
48 | 96.79 | 96.79 | 96.79 | 24729.50 | 39.0 | 48 | 12.4 | 0/0 | 2 |
|
Chip 2
|
A
|
2 | 99.96 | 99.92 | 99.79 | 0.10 | 62.2 | 2 | 19.7 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.91 | 99.76 | 0.18 | 103.9 | 0 | 33.0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.90 | 99.75 | 0.12 | 107.9 | 0 | 34.3 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.94 | 99.90 | 99.75 | 0.11 | 115.7 | 0 | 36.8 | 0/0 | 0 |
|
Chip 6
|
A
|
2 | 99.95 | 99.88 | 99.64 | 0.19 | 108.7 | 2 | 34.5 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.86 | 99.58 | 0.15 | 80.9 | 0 | 25.7 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.86 | 99.55 | 0.19 | 77.7 | 0 | 24.6 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.86 | 99.57 | 0.14 | 91.8 | 0 | 29.2 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.89 | 99.71 | 0.11 | 93.5 | 0 | 29.7 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.94 | 99.87 | 99.62 | 0.12 | 77.2 | 0 | 24.5 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.17 | 82.2 | 0 | 26.1 | 0/0 | 0 |
|
Chip 13
|
A
|
5 | 99.95 | 99.89 | 99.69 | 0.08 | 49.0 | 5 | 15.6 | 0/0 | 0 |
|
Chip 14
|
A
|
39 | 99.96 | 99.46 | -1.00 | 0.02 | 20.1 | 39 | 6.3 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.35 | -1.00 | 0.02 | 23.6 | 0 | 7.4 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
