Test Date: 2016-04-01 10:22
Analysis date: 2016-05-23 21:17
Analysis date: 2016-05-23 21:17
M-L-4-23 XRayHRQualification
Summary
| Module | Module | M-L-4-23 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 56 | |
| BumpBondingDefects | Bump Bonding Defects | 56 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.82/99.67 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.12 | 20.3 | 65.2 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
12 | 99.97 | 99.91 | 99.69 | 0.08 | 13.2 | 42.4 | 12 | 0/0 | 0 |
|
Chip 2
|
A
|
4 | 99.96 | 99.90 | 99.71 | 0.10 | 22.1 | 71.0 | 4 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.87 | 99.61 | 0.12 | 33.2 | 106.4 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.94 | 99.90 | 99.75 | 0.17 | 35.9 | 115.2 | 1 | 0/0 | 0 |
|
Chip 5
|
C
|
0 | 99.92 | 99.88 | 99.72 | 0.14 | 39.8 | 123.0 | 0 | 0/0 | 1 |
|
Chip 6
|
A
|
0 | 99.95 | 99.90 | 99.71 | 0.09 | 36.4 | 116.4 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
10 | 99.95 | 99.85 | 99.55 | 1.20 | 27.3 | 87.6 | 10 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.89 | 99.67 | 0.13 | 24.1 | 77.6 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.87 | 99.59 | 0.15 | 30.3 | 97.2 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.90 | 99.73 | 0.07 | 30.0 | 96.1 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.93 | 99.88 | 99.70 | 0.19 | 26.2 | 84.0 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.15 | 26.6 | 85.1 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
7 | 99.95 | 99.88 | 99.65 | 0.11 | 16.4 | 52.8 | 7 | 0/0 | 0 |
|
Chip 14
|
A
|
22 | 99.95 | 99.32 | -1.00 | 0.02 | 7.4 | 23.9 | 22 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.42 | -1.00 | 0.03 | 7.6 | 24.6 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 11 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
