Test Date: 2016-04-12 13:29
Analysis date: 2016-05-25 17:36
Analysis date: 2016-05-25 17:36
M-L-3-47 XRayHRQualification
Summary
| Module | Module | M-L-3-47 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 59 | |
| BumpBondingDefects | Bump Bonding Defects | 59 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.82/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.07 | 65.9 | 0 | 19.0 | 0/0 | 0 |
|
Chip 1
|
A
|
21 | 99.96 | 99.86 | 99.50 | 0.08 | 44.9 | 21 | 13.0 | 0/0 | 0 |
|
Chip 2
|
A
|
1 | 99.96 | 99.89 | 99.68 | 0.08 | 69.3 | 1 | 20.0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.87 | 99.63 | 0.08 | 107.7 | 0 | 31.2 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.93 | 99.81 | 99.41 | 2.51 | 114.8 | 0 | 33.3 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.90 | 99.74 | 0.09 | 117.9 | 0 | 34.2 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.94 | 99.90 | 99.77 | 0.13 | 117.7 | 0 | 34.1 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.17 | 84.8 | 0 | 24.5 | 0/0 | 0 |
|
Chip 8
|
A
|
1 | 99.95 | 99.90 | 99.73 | 0.10 | 80.8 | 1 | 23.4 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.88 | 99.67 | 0.22 | 101.3 | 0 | 29.4 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.90 | 99.77 | 0.16 | 101.7 | 0 | 29.4 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.19 | 85.8 | 0 | 24.8 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.91 | 99.74 | 0.13 | 90.6 | 0 | 26.2 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.95 | 99.89 | 99.71 | 0.09 | 53.2 | 9 | 15.4 | 0/0 | 0 |
|
Chip 14
|
A
|
27 | 99.95 | 99.25 | -1.00 | 0.02 | 22.9 | 27 | 6.6 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.56 | -1.00 | 0.03 | 24.6 | 0 | 7.1 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 3 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
