Test Date: 2016-04-29 15:33
Analysis date: 2016-05-24 02:59
Analysis date: 2016-05-24 02:59
M-L-3-21 XRayHRQualification
Summary
| Module | Module | M-L-3-21 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 54 | |
| BumpBondingDefects | Bump Bonding Defects | 54 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.81/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.55 | 0.15 | 60.0 | 0 | 19.4 | 0/0 | 0 |
|
Chip 1
|
A
|
17 | 99.94 | 99.85 | 99.53 | 0.14 | 47.1 | 17 | 15.2 | 0/0 | 0 |
|
Chip 2
|
A
|
3 | 99.96 | 99.87 | 99.57 | 0.09 | 75.7 | 3 | 24.5 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.90 | 99.75 | 0.09 | 120.8 | 0 | 39.2 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.90 | 99.72 | 0.08 | 124.3 | 0 | 40.3 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.91 | 99.72 | 0.13 | 122.0 | 0 | 39.6 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.94 | 99.90 | 99.78 | 0.10 | 126.5 | 0 | 41.0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.87 | 99.59 | 0.10 | 94.1 | 0 | 30.4 | 0/0 | 0 |
|
Chip 8
|
A
|
2 | 99.95 | 99.89 | 99.69 | 0.15 | 92.8 | 2 | 30.0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.97 | 99.87 | 99.55 | 0.09 | 109.2 | 0 | 35.4 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.86 | 99.57 | 0.17 | 109.5 | 0 | 35.4 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.94 | 99.88 | 99.67 | 0.11 | 95.7 | 1 | 31.0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.84 | 99.84 | 99.82 | 14.55 | 98.2 | 0 | 31.8 | 0/0 | 0 |
|
Chip 13
|
A
|
6 | 99.93 | 99.87 | 99.66 | 0.60 | 58.3 | 6 | 18.8 | 0/0 | 0 |
|
Chip 14
|
A
|
25 | 99.92 | 98.86 | -1.00 | 0.01 | 27.1 | 25 | 8.7 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.98 | 99.86 | -1.00 | 0.02 | 31.4 | 0 | 10.1 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
