Test Date: 2016-06-15 14:42
Analysis date: 2016-06-21 13:13
Analysis date: 2016-06-21 13:13
M-L-2-40 XRayHRQualification
Summary
| Module | Module | M-L-2-40 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 72 | |
| BumpBondingDefects | Bump Bonding Defects | 72 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.85/99.67 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.20 | 19.5 | 60.7 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
17 | 99.96 | 99.88 | 99.62 | 0.16 | 13.0 | 40.4 | 17 | 0/0 | 0 |
|
Chip 2
|
A
|
1 | 99.96 | 99.88 | 99.62 | 0.10 | 21.1 | 65.5 | 1 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.91 | 99.77 | 0.12 | 34.2 | 105.9 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.97 | 99.92 | 99.75 | 0.05 | 34.3 | 106.7 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.90 | 99.73 | 0.07 | 34.3 | 106.2 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.95 | 99.89 | 99.69 | 0.17 | 34.9 | 108.2 | 1 | 0/0 | 0 |
|
Chip 7
|
A
|
4 | 99.96 | 99.90 | 99.69 | 0.13 | 24.5 | 76.1 | 4 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.87 | 99.62 | 0.17 | 22.0 | 68.6 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.91 | 99.75 | 0.10 | 29.6 | 91.8 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.11 | 28.9 | 89.7 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.14 | 26.1 | 81.1 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
15 | 99.95 | 99.87 | 99.62 | 0.11 | 26.1 | 81.3 | 15 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.96 | 99.88 | 99.60 | 0.12 | 15.3 | 47.8 | 8 | 0/0 | 0 |
|
Chip 14
|
A
|
26 | 99.97 | 99.67 | -1.00 | 0.01 | 7.0 | 21.8 | 26 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.42 | -1.00 | 0.03 | 8.1 | 25.4 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 316 | |
| nWarnings | # Warnings | 8 | |
| channel_0_count | Channel 0 | 23 | |
| channel_1_count | Channel 1 | 18 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 27 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 5 | |
| message_notokenpass_count | has NoTokenPass | 7 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
