M-L-2-35 XRayHRQualification
Summary
| Module | Module | M-L-2-35 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 11/2/3 | |
| PixelDefects | Total Pixel Defects | 172 | |
| BumpBondingDefects | Bump Bonding Defects | 172 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.88/98.14/94.01 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.97 | 99.97 | 99.97 | 0.01 | 2.9 | 9.1 | 0 | 0/0 | 0 |
|
Chip 1
|
C
|
47 | 99.44 | 90.00 | 58.76 | 0.02 | 2.1 | 6.9 | 47 | 0/0 | 0 |
|
Chip 2
|
A
|
23 | 99.96 | 99.70 | 98.85 | 0.03 | 3.0 | 9.4 | 23 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 100.00 | 99.94 | 99.74 | 0.00 | 1.8 | 5.8 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.68 | 98.73 | 0.03 | 4.5 | 14.4 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.83 | 99.39 | 0.04 | 4.8 | 15.2 | 0 | 0/0 | 0 |
|
Chip 6
|
B
|
0 | 99.94 | 99.23 | 96.87 | 0.07 | 4.0 | 12.8 | 0 | 0/0 | 0 |
|
Chip 7
|
C
|
0 | 99.86 | 97.71 | 90.57 | 0.02 | 3.3 | 10.5 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.60 | 98.41 | 0.03 | 5.6 | 17.7 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.97 | 99.77 | 99.10 | 0.02 | 4.3 | 13.8 | 0 | 0/0 | 0 |
|
Chip 10
|
B
|
0 | 99.94 | 99.22 | 96.83 | 0.03 | 4.0 | 12.6 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.53 | 98.11 | 0.02 | 3.8 | 12.0 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.79 | 99.19 | 0.02 | 5.0 | 16.1 | 0 | 0/0 | 0 |
|
Chip 13
|
C
|
34 | 99.74 | 95.53 | 81.63 | 0.01 | 2.0 | 6.5 | 34 | 0/0 | 0 |
|
Chip 14
|
A
|
68 | 99.85 | 97.70 | -1.00 | 0.00 | 1.4 | 4.3 | 68 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.55 | 93.03 | -1.00 | 0.01 | 1.7 | 5.3 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 8 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
