Test Date: 2016-07-12 13:14
Analysis date: 2016-07-15 16:32
Analysis date: 2016-07-15 16:32
M-L-2-17 XRayHRQualification
Summary
| Module | Module | M-L-2-17 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 737 | |
| BumpBondingDefects | Bump Bonding Defects | 737 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.79/99.50 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.96 | 99.89 | 99.65 | 0.09 | 20.1 | 60.9 | 1 | 0/0 | 0 |
|
Chip 1
|
A
|
25 | 99.96 | 99.85 | 99.48 | 0.11 | 12.8 | 39.1 | 25 | 0/0 | 0 |
|
Chip 2
|
A
|
13 | 99.96 | 99.89 | 99.65 | 0.10 | 18.4 | 55.8 | 13 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.15 | 30.4 | 92.2 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.11 | 31.4 | 95.0 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
54 | 99.93 | 99.87 | 99.66 | 0.14 | 31.8 | 95.8 | 54 | 0/0 | 0 |
|
Chip 6
|
A
|
99 | 99.92 | 99.88 | 99.71 | 0.16 | 31.3 | 89.9 | 99 | 0/0 | 0 |
|
Chip 7
|
C
|
267 | 100.96 | 100.42 | 98.63 | 13.42 | 47.2 | 85.8 | 267 | 0/0 | 13 |
|
Chip 8
|
C
|
162 | 100.36 | 100.00 | 98.80 | 3.52 | 44.3 | 81.7 | 162 | 0/0 | 2 |
|
Chip 9
|
A
|
51 | 99.92 | 99.85 | 99.65 | 1.03 | 30.1 | 86.0 | 51 | 0/0 | 0 |
|
Chip 10
|
A
|
20 | 99.92 | 99.86 | 99.68 | 0.79 | 26.6 | 80.3 | 20 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.87 | 99.60 | 0.13 | 23.4 | 71.0 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.97 | 99.89 | 99.63 | 0.11 | 24.8 | 75.1 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
9 | 99.96 | 99.88 | 99.62 | 0.10 | 14.2 | 43.3 | 9 | 0/0 | 0 |
|
Chip 14
|
A
|
36 | 99.92 | 98.89 | -1.00 | 0.02 | 6.8 | 20.9 | 36 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.54 | -1.00 | 0.02 | 7.3 | 22.2 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 70 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
