M-L-1-48 XRayHRQualification
Summary
| Module | Module | M-L-1-48 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 178 | |
| BumpBondingDefects | Bump Bonding Defects | 178 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.83/99.35/99.45 | % |
| Noise | Mean Noise | -1 | e- |
