Test Date: 2016-04-07 13:27
Analysis date: 2016-05-23 19:01
Analysis date: 2016-05-23 19:01
M-K-3-22 XRayHRQualification
Summary
| Module | Module | M-K-3-22 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 88 | |
| BumpBondingDefects | Bump Bonding Defects | 88 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.84/99.66 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
3 | 99.96 | 99.87 | 99.55 | 0.08 | 65.2 | 3 | 20.4 | 0/0 | 0 |
|
Chip 1
|
A
|
15 | 99.96 | 99.88 | 99.61 | 0.09 | 44.2 | 15 | 13.8 | 0/0 | 0 |
|
Chip 2
|
A
|
26 | 99.96 | 99.89 | 99.64 | 0.07 | 66.4 | 26 | 20.8 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.10 | 107.7 | 0 | 33.6 | 0/0 | 0 |
|
Chip 4
|
A
|
2 | 99.93 | 99.88 | 99.71 | 0.08 | 112.3 | 2 | 35.1 | 0/0 | 0 |
|
Chip 5
|
A
|
2 | 99.97 | 99.89 | 99.61 | 0.13 | 116.5 | 2 | 36.5 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.94 | 99.88 | 99.69 | 0.16 | 117.1 | 0 | 36.6 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.95 | 99.91 | 99.77 | 0.19 | 85.8 | 1 | 26.7 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.12 | 75.8 | 0 | 23.6 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.16 | 97.1 | 0 | 30.4 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.12 | 92.8 | 0 | 29.0 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.96 | 99.91 | 99.73 | 0.09 | 84.1 | 1 | 26.2 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.91 | 99.74 | 0.09 | 83.3 | 0 | 26.0 | 0/0 | 0 |
|
Chip 13
|
A
|
5 | 99.96 | 99.88 | 99.63 | 0.13 | 50.3 | 5 | 15.7 | 0/0 | 0 |
|
Chip 14
|
A
|
33 | 99.96 | 99.46 | -1.00 | 0.02 | 22.6 | 33 | 7.0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.56 | -1.00 | 0.03 | 25.4 | 0 | 7.9 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 2 | |
| nErrors | # Errors | 20 | |
| nWarnings | # Warnings | 24 | |
| channel_0_count | Channel 0 | 3 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_eventid_count | Event ID mismatch | 2 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 1 | |
| message_missingevents_count | Missing Event criticals | 1 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
