M-K-3-22 XRayHRQualification
Summary
| Module | Module | M-K-3-22 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 0/0/16 | |
| PixelDefects | Total Pixel Defects | 26 | |
| BumpBondingDefects | Bump Bonding Defects | 26 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 16 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 16 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.84/99.69 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
3 | 99.96 | 99.90 | 99.72 | 0.09 | 57.3 | 3 | 14.3 | 5/16 | 0+82/7 |
|
Chip 1
|
C
|
0 | 99.96 | 99.89 | 99.63 | 0.12 | 40.8 | 0 | 10.2 | 5/15 | 0+50/7 |
|
Chip 2
|
C
|
18 | 99.96 | 99.89 | 99.68 | 0.05 | 60.1 | 18 | 15.0 | 5/15 | 0+64/7 |
|
Chip 3
|
C
|
0 | 99.96 | 99.89 | 99.66 | 0.13 | 96.2 | 0 | 24.0 | 5/16 | 0+110/14 |
|
Chip 4
|
C
|
2 | 99.97 | 99.92 | 99.75 | 0.10 | 98.1 | 2 | 24.6 | 5/16 | 0+111/16 |
|
Chip 5
|
C
|
1 | 99.96 | 99.91 | 99.73 | 0.11 | 100.8 | 1 | 25.3 | 5/16 | 0+109/15 |
|
Chip 6
|
C
|
0 | 99.96 | 99.90 | 99.71 | 0.22 | 102.7 | 0 | 25.7 | 6/17 | 0+111/15 |
|
Chip 7
|
C
|
1 | 99.96 | 99.91 | 99.74 | 0.07 | 71.5 | 1 | 17.9 | 5/15 | 0+85/7 |
|
Chip 8
|
C
|
0 | 99.97 | 99.89 | 99.64 | 0.09 | 64.2 | 0 | 16.0 | 5/16 | 0+95/6 |
|
Chip 9
|
C
|
0 | 99.96 | 99.91 | 99.74 | 0.10 | 81.8 | 0 | 20.6 | 5/15 | 0+106/13 |
|
Chip 10
|
C
|
0 | 99.96 | 99.88 | 99.62 | 0.14 | 78.9 | 0 | 19.8 | 5/15 | 0+104/10 |
|
Chip 11
|
C
|
1 | 99.96 | 99.89 | 99.67 | 0.08 | 76.2 | 1 | 19.0 | 6/16 | 0+105/14 |
|
Chip 12
|
C
|
0 | 99.96 | 99.88 | 99.63 | 0.13 | 72.5 | 0 | 18.1 | 5/15 | 0+105/12 |
|
Chip 13
|
C
|
0 | 99.96 | 99.90 | 99.70 | 0.13 | 45.7 | 0 | 11.4 | 5/14 | 0+60/8 |
|
Chip 14
|
C
|
0 | 99.96 | 99.47 | -1.00 | 0.02 | 22.3 | 0 | 5.5 | 4/13 | 0+13/0 |
|
Chip 15
|
C
|
0 | 99.95 | 99.41 | -1.00 | 0.03 | 25.7 | 0 | 6.4 | 5/14 | 0+4/0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 22 | |
| nWarnings | # Warnings | 156872 | |
| channel_0_count | Channel 0 | 3 | |
| channel_1_count | Channel 1 | 3 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_eventid_count | Event ID mismatch | 4 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
