M-K-2-32 XRayHRQualification
Summary
| Module | Module | M-K-2-32 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 0/0/16 | |
| PixelDefects | Total Pixel Defects | 970 | |
| BumpBondingDefects | Bump Bonding Defects | 970 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 2 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 16 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.78/99.61 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
1 | 99.93 | 99.83 | 99.48 | 0.23 | 33.2 | 1 | 0.0 | 0/0 | 47+0/17 |
|
Chip 1
|
C
|
245 | 99.95 | 99.86 | 99.56 | 0.19 | 21.1 | 245 | 0.0 | 0/0 | 49+0/15 |
|
Chip 2
|
C
|
155 | 99.95 | 99.88 | 99.63 | 0.09 | 33.0 | 155 | 0.0 | 0/0 | 50+0/6 |
|
Chip 3
|
C
|
0 | 99.96 | 99.87 | 99.57 | 0.19 | 51.5 | 0 | 0.0 | 0/0 | 41+0/22 |
|
Chip 4
|
C
|
0 | 99.93 | 99.87 | 99.66 | 0.14 | 54.4 | 0 | 0.0 | 0/0 | 43+0/19 |
|
Chip 5
|
C
|
4 | 99.92 | 99.89 | 99.77 | 0.13 | 58.9 | 4 | 0.0 | 0/0 | 40+0/111 |
|
Chip 6
|
C
|
0 | 99.94 | 99.86 | 99.61 | 0.12 | 58.5 | 0 | 0.0 | 0/0 | 32+0/137 |
|
Chip 7
|
C
|
3 | 99.94 | 99.87 | 99.62 | 0.17 | 40.3 | 3 | 0.0 | 0/0 | 43+0/34 |
|
Chip 8
|
C
|
0 | 99.95 | 99.86 | 99.57 | 0.16 | 35.8 | 0 | 0.0 | 0/1 | 50+0/12 |
|
Chip 9
|
C
|
0 | 99.96 | 99.88 | 99.61 | 0.13 | 47.9 | 0 | 0.0 | 0/0 | 51+0/2 |
|
Chip 10
|
C
|
71 | 99.95 | 99.88 | 99.66 | 0.08 | 47.5 | 71 | 0.0 | 0/0 | 44+0/39 |
|
Chip 11
|
C
|
2 | 99.95 | 99.87 | 99.62 | 0.09 | 40.4 | 2 | 0.0 | 0/0 | 38+0/34 |
|
Chip 12
|
C
|
0 | 99.95 | 99.87 | 99.59 | 0.15 | 41.3 | 0 | 0.0 | 0/0 | 43+0/28 |
|
Chip 13
|
C
|
171 | 99.94 | 99.86 | 99.61 | 0.12 | 25.6 | 171 | 0.0 | 0/0 | 36+0/75 |
|
Chip 14
|
C
|
318 | 99.91 | 98.64 | -1.00 | 0.03 | 10.0 | 318 | 0.0 | 0/0 | 52+0/2 |
|
Chip 15
|
C
|
0 | 99.96 | 99.63 | -1.00 | 0.03 | 9.9 | 0 | 0.0 | 0/2 | 52 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
