Test Date: 2016-03-15 11:31
Analysis date: 2016-05-21 13:37
Analysis date: 2016-05-21 13:37
M-J-4-09 XRayHRQualification
Summary
| Module | Module | M-J-4-09 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 76 | |
| BumpBondingDefects | Bump Bonding Defects | 76 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.62 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.86 | 99.55 | 0.10 | 16.5 | 56.3 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
19 | 99.97 | 99.87 | 99.53 | 0.11 | 10.1 | 34.5 | 19 | 0/0 | 0 |
|
Chip 2
|
A
|
12 | 99.96 | 99.87 | 99.58 | 0.09 | 15.0 | 51.5 | 12 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.11 | 22.9 | 78.2 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.89 | 99.65 | 0.11 | 25.2 | 86.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.89 | 99.67 | 0.08 | 26.4 | 90.0 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.13 | 26.7 | 91.1 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.96 | 99.87 | 99.57 | 0.15 | 19.3 | 65.8 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.89 | 99.64 | 0.10 | 18.3 | 62.5 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.88 | 99.65 | 0.11 | 23.3 | 79.5 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.16 | 22.7 | 77.3 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.95 | 99.88 | 99.64 | 0.18 | 19.1 | 65.2 | 1 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.94 | 99.87 | 99.62 | 0.20 | 19.7 | 67.1 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
13 | 99.96 | 99.88 | 99.63 | 0.09 | 12.2 | 41.7 | 13 | 0/0 | 0 |
|
Chip 14
|
A
|
31 | 99.95 | 99.38 | -1.00 | 0.02 | 4.6 | 15.9 | 31 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.63 | -1.00 | 0.03 | 4.9 | 17.0 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 495 | |
| nWarnings | # Warnings | 20 | |
| channel_0_count | Channel 0 | 33 | |
| channel_1_count | Channel 1 | 41 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 35 | |
| message_eventid_count | Event ID mismatch | 12 | |
| message_readback_count | Readback start marker | 19 | |
| message_notokenpass_count | has NoTokenPass | 8 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
