M-I-4-28 XRayHRQualification
Summary
| Module | Module | M-I-4-28 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 0/0/16 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 16 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 14 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
C
|
0 | 99.96 | 99.87 | 99.58 | 0.11 | 61.5 | 0 | 17.0 | 0/8 | 0+0/5 |
|
Chip 1
|
C
|
0 | 99.97 | 99.87 | 99.54 | 0.11 | 39.5 | 0 | 10.9 | 0/7 | 0+0/4 |
|
Chip 2
|
C
|
0 | 99.97 | 99.91 | 99.71 | 0.08 | 64.3 | 0 | 17.8 | 0/8 | 0+0/24 |
|
Chip 3
|
C
|
0 | 99.96 | 99.90 | 99.70 | 0.11 | 93.3 | 0 | 26.1 | 0/9 | 0+0/21 |
|
Chip 4
|
C
|
0 | 99.96 | 99.90 | 99.72 | 0.11 | 95.1 | 0 | 26.6 | 0/9 | 0+0/12 |
|
Chip 5
|
C
|
0 | 99.95 | 99.88 | 99.68 | 0.15 | 96.9 | 0 | 27.2 | 0/9 | 0+0/22 |
|
Chip 6
|
C
|
0 | 99.96 | 99.88 | 99.64 | 0.12 | 105.8 | 0 | 29.5 | 0/9 | 0+0/71 |
|
Chip 7
|
C
|
0 | 99.95 | 99.86 | 99.57 | 0.14 | 79.0 | 0 | 21.8 | 0/9 | 0+0/6 |
|
Chip 8
|
C
|
0 | 99.96 | 99.89 | 99.67 | 0.17 | 73.8 | 0 | 20.5 | 0/9 | 0+0/5 |
|
Chip 9
|
C
|
1 | 99.96 | 99.90 | 99.73 | 0.11 | 101.3 | 1 | 28.0 | 0/9 | 0+0/27 |
|
Chip 10
|
C
|
0 | 99.95 | 99.88 | 99.63 | 0.13 | 105.0 | 0 | 29.2 | 0/9 | 0+0/65 |
|
Chip 11
|
C
|
0 | 99.95 | 99.86 | 99.56 | 0.13 | 79.3 | 0 | 22.1 | 0/9 | 0+0/10 |
|
Chip 12
|
C
|
0 | 99.96 | 99.90 | 99.67 | 0.08 | 79.3 | 0 | 22.1 | 0/9 | 0+0/10 |
|
Chip 13
|
C
|
0 | 99.95 | 99.87 | 99.61 | 0.16 | 48.3 | 0 | 13.4 | 0/8 | 0+0/5 |
|
Chip 14
|
C
|
0 | 99.94 | 99.18 | -1.00 | 0.02 | 24.3 | 0 | 6.7 | 0/7 | 0 |
|
Chip 15
|
C
|
0 | 99.97 | 99.78 | -1.00 | 0.03 | 30.0 | 0 | 8.2 | 0/7 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 19 | |
| nWarnings | # Warnings | 195589 | |
| channel_0_count | Channel 0 | 2 | |
| channel_1_count | Channel 1 | 1 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 2 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 1 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
