Test Date: 2016-05-27 10:35
Analysis date: 2016-06-02 13:43
Analysis date: 2016-06-02 13:43
M-I-3-50 XRayHRQualification
Summary
| Module | Module | M-I-3-50 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 236 | |
| BumpBondingDefects | Bump Bonding Defects | 236 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.83/99.62 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.87 | 99.56 | 0.10 | 18.6 | 58.8 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
19 | 99.95 | 99.85 | 99.50 | 0.08 | 12.4 | 39.1 | 19 | 0/0 | 0 |
|
Chip 2
|
A
|
11 | 99.95 | 99.87 | 99.61 | 0.08 | 19.9 | 62.7 | 11 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.88 | 99.68 | 0.13 | 31.9 | 100.3 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.11 | 33.5 | 105.5 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.94 | 99.88 | 99.69 | 0.13 | 34.1 | 107.5 | 1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.92 | 99.86 | 99.66 | 0.14 | 34.0 | 107.1 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.88 | 99.67 | 0.09 | 24.3 | 76.6 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.86 | 99.58 | 0.12 | 25.7 | 81.2 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.13 | 26.6 | 83.9 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.10 | 26.7 | 84.2 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.16 | 23.1 | 73.0 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.19 | 24.6 | 77.8 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
8 | 99.95 | 99.84 | 99.46 | 0.08 | 14.5 | 45.9 | 8 | 0/0 | 0 |
|
Chip 14
|
A
|
37 | 99.94 | 99.18 | -1.00 | 0.02 | 6.8 | 21.5 | 37 | 0/0 | 0 |
|
Chip 15
|
C
|
160 | 100.00 | 99.94 | -1.00 | 0.00 | 8.1 | 25.8 | 160 | 0/0 | 2 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 52 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
