Test Date: 2016-02-26 10:27
Analysis date: 2016-05-25 12:17
Analysis date: 2016-05-25 12:17
M-I-3-08 XRayHRQualification
Summary
| Module | Module | M-I-3-08 | |
| Grade | Grade | B | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/1/0 | |
| PixelDefects | Total Pixel Defects | 93 | |
| BumpBondingDefects | Bump Bonding Defects | 93 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.70/95.44/99.65 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "90" | BB def | Rate "30" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.97 | 99.89 | 99.64 | 0.07 | 58.0 | 0 | 15.2 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.97 | 99.90 | 99.67 | 0.08 | 38.5 | 0 | 10.1 | 0/0 | 0 |
|
Chip 2
|
A
|
1 | 99.95 | 99.86 | 99.55 | 1.16 | 66.5 | 1 | 17.2 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.10 | 96.6 | 0 | 25.3 | 0/0 | 0 |
|
Chip 4
|
A
|
1 | 99.96 | 99.90 | 99.72 | 0.13 | 94.5 | 1 | 25.1 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.12 | 108.0 | 0 | 28.3 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.07 | 114.5 | 0 | 29.9 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.96 | 99.88 | 99.61 | 0.12 | 81.4 | 1 | 21.2 | 0/0 | 0 |
|
Chip 8
|
A
|
62 | 99.92 | 99.87 | 99.71 | 2.46 | 75.4 | 62 | 19.6 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.86 | 99.54 | 0.12 | 88.5 | 0 | 23.3 | 0/0 | 0 |
|
Chip 10
|
A
|
26 | 99.96 | 99.88 | 99.62 | 0.20 | 92.8 | 26 | 24.2 | 0/0 | 0 |
|
Chip 11
|
A
|
2 | 99.96 | 99.88 | 99.63 | 0.13 | 75.7 | 2 | 19.8 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.87 | 99.58 | 0.13 | 81.1 | 0 | 21.1 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.95 | 99.91 | 99.74 | 0.12 | 45.2 | 0 | 11.8 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.94 | 99.17 | -1.00 | 0.05 | 23.8 | 0 | 6.2 | 0/0 | 0 |
|
Chip 15
|
B
|
0 | 95.87 | 29.44 | -1.00 | 30.78 | 32.1 | 0 | 8.7 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
