Test Date: 2016-06-02 13:24
Analysis date: 2016-06-09 12:42
Analysis date: 2016-06-09 12:42
M-I-2-30 XRayHRQualification
Summary
| Module | Module | M-I-2-30 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 239 | |
| BumpBondingDefects | Bump Bonding Defects | 239 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.96/99.83/99.68 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.96 | 99.90 | 99.71 | 0.09 | 17.8 | 55.9 | 1 | 0/0 | 0 |
|
Chip 1
|
A
|
24 | 99.96 | 99.91 | 99.71 | 0.11 | 11.9 | 37.4 | 24 | 0/0 | 0 |
|
Chip 2
|
C
|
166 | 99.96 | 99.92 | 99.79 | 0.08 | 18.9 | 59.6 | 166 | 0/0 | 2 |
|
Chip 3
|
A
|
0 | 99.96 | 99.91 | 99.73 | 0.09 | 30.7 | 96.5 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.17 | 31.2 | 98.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
3 | 99.95 | 99.90 | 99.73 | 0.21 | 33.1 | 103.9 | 3 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.94 | 99.89 | 99.73 | 0.16 | 31.7 | 99.5 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
1 | 99.95 | 99.87 | 99.60 | 0.12 | 21.8 | 68.6 | 1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.87 | 99.62 | 0.12 | 22.4 | 70.5 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.88 | 99.62 | 0.20 | 26.6 | 83.4 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.89 | 99.64 | 0.15 | 26.0 | 81.7 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
2 | 99.96 | 99.88 | 99.62 | 0.13 | 21.9 | 68.8 | 2 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.96 | 99.89 | 99.65 | 0.13 | 22.9 | 72.3 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
11 | 99.96 | 99.91 | 99.72 | 0.09 | 14.1 | 44.3 | 11 | 0/0 | 0 |
|
Chip 14
|
A
|
30 | 99.95 | 99.27 | -1.00 | 0.02 | 6.4 | 20.2 | 30 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.57 | -1.00 | 0.03 | 7.6 | 23.9 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 10 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
