M-H-2-41 XRayHRQualification
Summary
| Module | Module | M-H-2-41 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 13/2/1 | |
| PixelDefects | Total Pixel Defects | 1 | |
| BumpBondingDefects | Bump Bonding Defects | 1 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.59/99.10/97.83 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "130" | BB def | Rate "60" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.94 | 99.85 | 99.56 | 0.19 | 86.2 | 0 | 40.5 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.66 | 99.44 | 98.72 | 4.59 | 61.4 | 0 | 28.8 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.91 | 99.74 | 99.18 | 0.55 | 88.2 | 0 | 41.4 | 0/0 | 0 |
|
Chip 3
|
B
|
0 | 99.06 | 98.29 | 95.74 | 8.28 | 125.1 | 0 | 58.9 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.87 | 99.61 | 0.19 | 137.6 | 0 | 64.8 | 0/0 | 0 |
|
Chip 5
|
B
|
0 | 99.19 | 98.59 | 96.61 | 10.13 | 147.2 | 0 | 69.4 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.66 | 99.43 | 98.69 | 4.45 | 143.0 | 0 | 67.4 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.72 | 99.56 | 99.00 | 2.34 | 109.2 | 0 | 51.2 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.93 | 99.84 | 99.51 | 0.26 | 102.2 | 0 | 47.9 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.77 | 99.54 | 98.80 | 2.41 | 128.2 | 0 | 60.2 | 0/0 | 0 |
|
Chip 10
|
A
|
1 | 99.95 | 99.85 | 99.51 | 0.24 | 125.3 | 1 | 58.9 | 0/0 | 0 |
|
Chip 11
|
C
|
0 | 97.39 | 94.98 | 87.00 | 357.12 | 124.5 | 0 | 62.4 | 0/0 | 1 |
|
Chip 12
|
A
|
0 | 99.95 | 99.84 | 99.48 | 0.14 | 103.8 | 0 | 48.8 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.63 | 99.30 | 98.18 | 3.12 | 65.1 | 0 | 30.5 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.86 | 98.20 | -1.00 | 0.08 | 31.2 | 0 | 14.6 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.93 | 99.21 | -1.00 | 0.12 | 36.8 | 0 | 17.2 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
