M-H-1-13 XRayHRQualification
Summary
| Module | Module | M-H-1-13 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 14/0/2 | |
| PixelDefects | Total Pixel Defects | 4167 | |
| BumpBondingDefects | Bump Bonding Defects | 4167 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 2 | |
| Efficiency | Efficiency 20/50/80 | 93.69/93.59/92.59 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "60" | Rate "130" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.89 | 99.68 | 0.10 | 43.0 | 84.4 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
3 | 99.96 | 99.90 | 99.72 | 0.09 | 29.6 | 58.2 | 3 | 0/0 | 0 |
|
Chip 2
|
C
|
4160 | 0.00 | 0.00 | 0.00 | -1 | 0.0 | 0.0 | 4160 | 0/0 | 52 |
|
Chip 3
|
A
|
0 | 99.94 | 99.90 | 99.78 | 0.16 | 70.5 | 138.1 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.90 | 99.76 | 0.11 | 73.5 | 144.2 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.95 | 99.89 | 99.67 | 0.14 | 76.2 | 149.1 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.91 | 99.75 | 0.10 | 74.0 | 144.9 | 0 | 0/0 | 0 |
|
Chip 7
|
C
|
0 | 99.73 | 99.71 | 99.63 | 7.17 | 52.7 | 92.8 | 0 | 0/0 | 6 |
|
Chip 8
|
A
|
0 | 99.95 | 99.90 | 99.71 | 0.15 | 39.5 | 77.6 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.13 | 65.9 | 129.1 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.89 | 99.69 | 0.12 | 62.4 | 122.4 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.96 | 99.89 | 99.66 | 0.13 | 55.1 | 108.1 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
3 | 99.94 | 99.89 | 99.73 | 0.11 | 63.0 | 123.5 | 3 | 0/0 | 0 |
|
Chip 13
|
A
|
1 | 99.96 | 99.90 | 99.72 | 0.13 | 37.3 | 73.2 | 1 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.96 | 99.54 | -1.00 | 0.02 | 15.6 | 30.8 | 0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.43 | -1.00 | 0.02 | 16.4 | 32.4 | 0 | 0/0 | 0 |
