Test Date: 2016-01-19 11:04
Analysis date: 2016-05-25 08:39
Analysis date: 2016-05-25 08:39
M-G-3-06 XRayHRQualification
Summary
| Module | Module | M-G-3-06 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 81 | |
| BumpBondingDefects | Bump Bonding Defects | 81 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.93/99.76/99.58 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "60" | Rate "130" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.90 | 99.70 | 0.14 | 50.8 | 104.2 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
1 | 99.91 | 99.78 | 99.33 | 2.77 | 35.8 | 73.7 | 1 | 0/0 | 0 |
|
Chip 2
|
A
|
1 | 99.89 | 99.78 | 99.44 | 3.35 | 53.3 | 109.3 | 1 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.90 | 99.77 | 0.08 | 82.5 | 169.2 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.94 | 99.94 | 0.05 | 94.7 | 194.0 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.98 | 99.83 | 99.33 | 0.11 | 98.0 | 200.5 | 0 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.95 | 99.88 | 99.65 | 0.06 | 95.0 | 194.5 | 0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.36 | 65.3 | 134.2 | 0 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.21 | 60.4 | 124.5 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
77 | 99.75 | 99.60 | 99.11 | 84.40 | 72.7 | 149.1 | 77 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.95 | 99.89 | 99.66 | 0.14 | 76.3 | 156.9 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.89 | 99.66 | 0.19 | 62.5 | 128.4 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.96 | 99.91 | 99.74 | 0.12 | 64.3 | 132.3 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.97 | 99.87 | 99.52 | 0.10 | 39.9 | 82.2 | 0 | 0/0 | 0 |
|
Chip 14
|
A
|
1 | 99.87 | 98.43 | -1.00 | 0.86 | 17.0 | 35.2 | 1 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.97 | 99.74 | -1.00 | 0.01 | 19.2 | 39.6 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
