Test Date: 2016-01-29 10:54
Analysis date: 2016-05-24 07:46
Analysis date: 2016-05-24 07:46
M-G-2-40 XRayHRQualification
Summary
| Module | Module | M-G-2-40 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 12/1/3 | |
| PixelDefects | Total Pixel Defects | 126 | |
| BumpBondingDefects | Bump Bonding Defects | 126 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 3 | |
| Efficiency | Efficiency 20/50/80 | 99.84/99.58/99.05 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "130" | BB def | Rate "60" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.83 | 99.68 | 99.19 | 1.92 | 106.4 | 0 | 55.7 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.95 | 99.87 | 99.60 | 0.18 | 78.6 | 0 | 41.0 | 0/0 | 0 |
|
Chip 2
|
A
|
1 | 99.94 | 99.80 | 99.33 | 0.19 | 113.7 | 1 | 59.4 | 0/0 | 0 |
|
Chip 3
|
C
|
0 | 99.93 | 99.84 | 99.55 | 0.22 | 189.1 | 0 | 103.8 | 0/0 | 3 |
|
Chip 4
|
C
|
125 | 100.02 | 99.46 | 97.59 | 6.10 | 164.2 | 125 | 85.7 | 0/0 | 1 |
|
Chip 5
|
B
|
0 | 99.07 | 98.61 | 97.09 | 11.66 | 186.4 | 0 | 97.7 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.90 | 99.84 | 99.65 | 0.36 | 189.3 | 0 | 99.2 | 0/0 | 0 |
|
Chip 7
|
C
|
0 | 99.96 | 99.71 | 98.87 | 3.23 | 144.2 | 0 | 79.1 | 0/0 | 3 |
|
Chip 8
|
A
|
0 | 99.63 | 99.28 | 98.10 | 3.29 | 114.8 | 0 | 59.9 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.93 | 99.85 | 99.55 | 0.20 | 151.1 | 0 | 79.1 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.89 | 99.80 | 99.52 | 0.49 | 155.2 | 0 | 81.2 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.93 | 99.85 | 99.59 | 0.17 | 132.8 | 0 | 69.4 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.94 | 99.86 | 99.59 | 0.17 | 138.7 | 0 | 72.5 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.89 | 99.79 | 99.44 | 0.53 | 81.8 | 0 | 42.7 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.89 | 98.56 | -1.00 | 0.05 | 38.7 | 0 | 20.2 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.54 | -1.00 | 0.03 | 41.1 | 0 | 21.3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
