M-G-2-29 XRayHRQualification
Summary
| Module | Module | M-G-2-29 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 13/0/3 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 3 | |
| Efficiency | Efficiency 20/50/80 | 99.83/99.07/99.29 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "130" | BB def | Rate "60" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.85 | 99.55 | 0.11 | 111.1 | 0 | 58.2 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.95 | 99.87 | 99.61 | 0.12 | 78.8 | 0 | 41.2 | 0/0 | 0 |
|
Chip 2
|
C
|
2 | 99.69 | 99.35 | 98.21 | 1.23 | 114.7 | 2 | 60.2 | 0/0 | 0+6/0 |
|
Chip 3
|
A
|
0 | 99.76 | 99.68 | 99.41 | 0.86 | 182.7 | 0 | 96.0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.94 | 99.85 | 99.54 | 0.27 | 194.9 | 0 | 102.3 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.63 | 99.63 | 99.63 | 2.30 | 196.0 | 0 | 102.9 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.99 | 99.78 | 99.09 | 0.46 | 207.7 | 1 | 109.2 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.92 | 99.70 | 99.00 | 0.54 | 151.8 | 0 | 79.5 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.95 | 99.87 | 99.59 | 0.12 | 134.5 | 0 | 70.2 | 0/0 | 0 |
|
Chip 9
|
C
|
0 | 99.87 | 99.74 | 99.28 | 0.40 | 172.4 | 0 | 91.9 | 0/0 | 1 |
|
Chip 10
|
A
|
0 | 99.92 | 99.80 | 99.42 | 0.36 | 170.3 | 0 | 89.4 | 0/0 | 0 |
|
Chip 11
|
C
|
0 | 99.66 | 99.44 | 98.70 | 20.15 | 149.2 | 0 | 79.8 | 0/0 | 1 |
|
Chip 12
|
A
|
0 | 99.93 | 99.81 | 99.42 | 0.21 | 145.7 | 0 | 76.4 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.96 | 99.87 | 99.56 | 0.10 | 83.7 | 0 | 43.8 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.22 | 89.12 | -1.00 | 1.04 | 38.0 | 0 | 19.8 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.78 | -1.00 | 0.05 | 45.7 | 0 | 23.8 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
