Test Date: 2016-04-20 13:19
Analysis date: 2016-05-25 07:38
Analysis date: 2016-05-25 07:38
M-G-2-08 XRayHRQualification
Summary
| Module | Module | M-G-2-08 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 137 | |
| BumpBondingDefects | Bump Bonding Defects | 137 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.94/99.81/99.63 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "120" | BB def | Rate "40" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.11 | 75.2 | 0 | 23.4 | 0/0 | 0 |
|
Chip 1
|
A
|
12 | 99.96 | 99.90 | 99.72 | 0.06 | 49.2 | 12 | 15.3 | 0/0 | 0 |
|
Chip 2
|
A
|
2 | 99.97 | 99.90 | 99.67 | 0.04 | 69.3 | 2 | 21.6 | 0/0 | 0 |
|
Chip 3
|
A
|
1 | 99.95 | 99.90 | 99.71 | 0.21 | 110.9 | 1 | 34.6 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.93 | 99.91 | 99.83 | 0.06 | 119.9 | 0 | 37.4 | 0/0 | 0 |
|
Chip 5
|
A
|
4 | 99.95 | 99.90 | 99.75 | 0.11 | 118.7 | 4 | 37.0 | 0/0 | 0 |
|
Chip 6
|
A
|
3 | 99.94 | 99.90 | 99.78 | 0.10 | 120.6 | 3 | 37.6 | 0/0 | 0 |
|
Chip 7
|
A
|
5 | 99.96 | 99.88 | 99.60 | 0.09 | 80.7 | 5 | 25.1 | 0/0 | 0 |
|
Chip 8
|
A
|
10 | 99.95 | 99.88 | 99.64 | 0.12 | 84.0 | 10 | 26.1 | 0/0 | 0 |
|
Chip 9
|
A
|
1 | 99.95 | 99.87 | 99.62 | 0.10 | 118.1 | 1 | 36.8 | 0/0 | 0 |
|
Chip 10
|
C
|
80 | 99.72 | 99.50 | 98.78 | 0.60 | 112.0 | 80 | 34.9 | 0/0 | 1 |
|
Chip 11
|
A
|
1 | 99.94 | 99.88 | 99.68 | 0.14 | 97.2 | 1 | 30.3 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.95 | 99.90 | 99.72 | 0.04 | 100.8 | 1 | 31.4 | 0/0 | 0 |
|
Chip 13
|
A
|
1 | 99.95 | 99.89 | 99.68 | 0.10 | 57.7 | 1 | 17.9 | 0/0 | 0 |
|
Chip 14
|
A
|
16 | 99.94 | 99.26 | -1.00 | 0.02 | 23.1 | 16 | 7.1 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.58 | -1.00 | 0.02 | 25.5 | 0 | 7.9 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 40 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
