Test Date: 2016-01-25 11:12
Analysis date: 2016-05-23 16:36
Analysis date: 2016-05-23 16:36
M-G-1-40 XRayHRQualification
Summary
| Module | Module | M-G-1-40 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 8 | |
| BumpBondingDefects | Bump Bonding Defects | 8 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.89/99.77/99.59 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "130" | BB def | Rate "60" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.95 | 99.89 | 99.68 | 0.14 | 97.1 | 1 | 47.7 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.50 | 99.49 | 99.47 | 132.10 | 69.1 | 0 | 33.9 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.70 | 99.45 | 98.63 | 85.39 | 101.9 | 0 | 50.0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.93 | 99.86 | 99.63 | 0.14 | 162.7 | 0 | 80.0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.93 | 99.89 | 99.77 | 0.16 | 165.1 | 0 | 81.4 | 0/0 | 0 |
|
Chip 5
|
A
|
3 | 99.98 | 99.89 | 99.59 | 0.14 | 175.9 | 3 | 86.7 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.93 | 99.86 | 99.60 | 0.18 | 180.8 | 0 | 89.0 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.95 | 99.88 | 99.66 | 0.11 | 136.3 | 0 | 66.8 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.93 | 99.88 | 99.72 | 0.32 | 120.8 | 0 | 59.3 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.91 | 99.85 | 99.66 | 0.17 | 153.3 | 0 | 75.3 | 0/0 | 0 |
|
Chip 10
|
A
|
3 | 99.92 | 99.88 | 99.72 | 0.14 | 153.8 | 3 | 75.5 | 0/0 | 0 |
|
Chip 11
|
A
|
1 | 99.94 | 99.89 | 99.71 | 0.14 | 130.3 | 1 | 63.9 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.93 | 99.89 | 99.73 | 0.12 | 132.3 | 0 | 64.8 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.90 | 99.84 | 99.63 | 2.95 | 83.4 | 0 | 40.8 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.96 | 99.44 | -1.00 | 0.02 | 36.7 | 0 | 17.9 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.46 | -1.00 | 0.04 | 44.4 | 0 | 21.7 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
