Test Date: 2016-01-25 11:16
Analysis date: 2016-05-21 22:12
Analysis date: 2016-05-21 22:12
M-G-1-40 XRayHRQualification
Summary
| Module | Module | M-G-1-40 | |
| Grade | Grade | A | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 16/0/0 | |
| PixelDefects | Total Pixel Defects | 52 | |
| BumpBondingDefects | Bump Bonding Defects | 52 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.80/99.64 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "40" | Rate "120" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
1 | 99.95 | 99.86 | 99.55 | 0.17 | 22.0 | 63.4 | 1 | 0/0 | 0 |
|
Chip 1
|
A
|
12 | 99.96 | 99.86 | 99.52 | 0.11 | 15.3 | 44.1 | 12 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.97 | 99.89 | 99.63 | 0.05 | 23.0 | 66.4 | 0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.88 | 99.63 | 0.13 | 37.6 | 108.2 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.95 | 99.88 | 99.64 | 0.11 | 38.3 | 110.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
5 | 99.94 | 99.91 | 99.79 | 0.11 | 41.0 | 117.8 | 5 | 0/0 | 0 |
|
Chip 6
|
A
|
1 | 99.94 | 99.87 | 99.65 | 0.09 | 42.1 | 121.2 | 1 | 0/0 | 0 |
|
Chip 7
|
A
|
2 | 99.96 | 99.90 | 99.69 | 0.13 | 29.2 | 84.5 | 2 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.67 | 0.17 | 25.6 | 74.1 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.94 | 99.87 | 99.62 | 0.19 | 35.8 | 103.2 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
8 | 99.95 | 99.86 | 99.59 | 0.13 | 35.7 | 103.1 | 8 | 0/0 | 0 |
|
Chip 11
|
A
|
2 | 99.95 | 99.90 | 99.74 | 0.11 | 30.1 | 86.9 | 2 | 0/0 | 0 |
|
Chip 12
|
A
|
1 | 99.96 | 99.88 | 99.64 | 0.11 | 30.5 | 88.0 | 1 | 0/0 | 0 |
|
Chip 13
|
A
|
4 | 99.96 | 99.88 | 99.63 | 0.12 | 18.8 | 54.5 | 4 | 0/0 | 0 |
|
Chip 14
|
A
|
16 | 99.94 | 99.07 | -1.00 | 0.02 | 7.8 | 22.6 | 16 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.95 | 99.46 | -1.00 | 0.03 | 9.4 | 27.3 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 270 | |
| nWarnings | # Warnings | 16 | |
| channel_0_count | Channel 0 | 22 | |
| channel_1_count | Channel 1 | 24 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 20 | |
| message_eventid_count | Event ID mismatch | 6 | |
| message_readback_count | Readback start marker | 16 | |
| message_notokenpass_count | has NoTokenPass | 4 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
