Test Date: 2016-02-03 14:52
Analysis date: 2016-05-24 11:23
Analysis date: 2016-05-24 11:23
M-B-5-25 ModuleFPIXTest_p17_1
_
Summary 1
| Module | Module | M-B-5-25 | |
| Grade | Grade | B | |
| ElectricalGrade | Electrical Grade | B | |
| IVGrade | IV Grade | A | |
| ManualGrade | Manual Grade | None | |
| PixelDefects | Pixel Defects - A/B/C | 134 - 15/1/0 | |
| DeadPixels | Dead Pixels | 5 | |
| AddressProblems | Address Problems | 0 | |
| ThresholdDefects | Threshold Defects | 2 | |
| MaskDefects | Mask Defects | 0 | |
| DeadBumps | Dead Bumps | 127 | |
| NoisyPixels | Noise Defects | 0 | |
| TrimProblems | Trim Problems | 0 | |
| PHGainDefects | PH Gain Defects | 0 | |
| PHPedestalDefects | PH Pedestal Defects | 0 | |
| PHPar1Defects | PH Parameter1 Defects | 5 |
Summary 2
| TestCenter | Test Center | FNAL | |
| TestDate | Test Date | 2016-02-03 | |
| TestTime | Test Time | 14:52 | |
| TestDuration | Test Duration | 1:20:12 | |
| TempC | Temparature | 17 | °C |
| TrimPHCal | Trim / phCal | yes / yes | |
| TermCycl | Term. Cycl. | yes | |
| TBM1 | TBM1 | ok, 0x84 0x49 | |
| TBM2 | TBM2 | ok, 0x00 0x49 | |
| PxarVersion | pXar | prod-12 | |
| ModuleIa | Module Ia | 377 | mA |
IVCurve
Summary 3
| Noise | Noise | 116.95 | e |
| NoiseROCs | Noise grades | 16/0/0 | |
| VcalThrWidth | Vcal Thr. Width | 43.38 | e |
| VcalThrWidthROCs | Vcal Thr. W. grades | 16/0/0 | |
| RelGainWidth | Rel. Gain Width | 0.03 | % |
| RelGainWidthROCs | Rel. Gain W. grades | 16/0/0 | |
| PedestalSpread | Pedestal Spread | 1056.56 | e |
| PedestalSpreadROCs | Ped. Spread grades | 16/0/0 | |
| Parameter1 | Parameter1 | 0.67 | |
| Parameter1ROCs | Par1 grades | 16/0/0 | |
| CurrentAtVoltage150V | I(150 V) | 0.03 | μA |
| CurrentVariation | I(150 V) / I(100 V) | 1.00 |
Digital Current
| Duration | Duration | 1:20:12 | |
| MinCurrent | min. Current | 0.436 | A |
| MaxCurrent | max. Current | 0.472 | A |
Analog Current
| Duration | Duration | 1:20:12 | |
| MinCurrent | min. Current | 0.371 | A |
| MaxCurrent | max. Current | 0.379 | A |
| ModuleIa | Module Ia | 377 | mA |
IanaLoss
| IanaLossProblems | Iana problems | No | |
| Mean | mean | 19.15 | |
| Min | min | 18.50 | |
| Max | max | 20.10 |
Temperature
| Temperature | Temp. while test | 17.00 +/- 0.17 | °C |
| Duration | Duration of test | 0:05:13 |
Summary ROCs
| ROC | Grade | Total | Dead | Mask | Bumps | Trim(Bits) | Address | Noise | Thresh | Gain | Ped | Par1 | Mean noise | Thr [e-] | Thr width | Rel gain width | Ped spread |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Chip 0 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
112.53
|
1751 |
42
|
0.031
|
938
|
| Chip 1 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
111.83
|
1750 |
42
|
0.034
|
1082
|
| Chip 2 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
106.26
|
1754 |
42
|
0.037
|
993
|
| Chip 3 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
103.78
|
1751 |
40
|
0.029
|
1078
|
| Chip 4 |
A
|
1
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
1
|
110.58
|
1753 |
41
|
0.026
|
996
|
| Chip 5 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
112.22
|
1758 |
42
|
0.034
|
1042
|
| Chip 6 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
116.65
|
1753 |
42
|
0.037
|
1024
|
| Chip 7 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
119.27
|
1752 |
44
|
0.028
|
1046
|
| Chip 8 |
A
|
1
|
0
|
0
|
1
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
115.67
|
1762 |
44
|
0.036
|
940
|
| Chip 9 |
A
|
2
|
0
|
0
|
2
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
118.51
|
1752 |
44
|
0.025
|
1079
|
| Chip 10 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
115.81
|
1757 |
43
|
0.036
|
1118
|
| Chip 11 |
A
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
0
|
113.76
|
1752 |
42
|
0.028
|
978
|
| Chip 12 |
A
|
2
|
0
|
0
|
1
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
134.73
|
1754 |
49
|
0.029
|
1036
|
| Chip 13 |
A
|
8
|
2
|
0
|
6
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
119.33
|
1750 |
45
|
0.039
|
1022
|
| Chip 14 |
A
|
36
|
2
|
0
|
34
|
0
|
0
|
0
|
0
|
0
|
0
|
2
|
132.28
|
1751 |
46
|
0.033
|
1271
|
| Chip 15 |
B
|
82
|
0
|
0
|
81
|
0
|
0
|
0
|
1
|
0
|
0
|
0
|
127.93
|
1754 |
46
|
0.028
|
1262
|
TBM
| nTBMs | n | 1 | |
| TBMType | Type | tbm08c | |
| Core0a_basea | Core 0a base a | 0x49 | |
| Core0a_basee | Core 0a base e | 0x84 | |
| Core0b_basea | Core 0b base a | 0x49 | |
| Core0b_basee | Core 0b base e | 0x00 | |
| RocDelay_Ch0 | Roc Delay Ch0 | 1 | |
| RocDelay_Ch1 | Roc Delay Ch1 | 1 | |
| RocDelay_Ch2 | Roc Delay Ch2 | 1 | |
| RocDelay_Ch3 | Roc Delay Ch3 | 1 | |
| Phase400 | Phase 400 | 1 | |
| Phase160 | Phase 160 | 4 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
GradingParameters
| ModifiedGrading | Modified Grading | ? | |
| GradingParameters_XRayHighRateEfficiency_NInterpolationRates | XRayHighRateEfficiency_NInterpolationRates | 2 => 3 |
