Test Date: 2016-01-25 11:12
Analysis date: 2016-05-23 04:54
Analysis date: 2016-05-23 04:54
M-B-4-44 XRayHRQualification
Summary
| Module | Module | M-B-4-44 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 13/1/2 | |
| PixelDefects | Total Pixel Defects | 5 | |
| BumpBondingDefects | Bump Bonding Defects | 5 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 0 | |
| Efficiency | Efficiency 20/50/80 | 94.79/96.87/86.43 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "130" | BB def | Rate "60" | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.95 | 99.89 | 99.66 | 0.12 | 60.5 | 0 | 60.5 | 0/0 | 0 |
|
Chip 1
|
B
|
0 | 99.29 | 98.60 | 96.31 | 249.81 | 42.4 | 0 | 42.4 | 0/0 | 0 |
|
Chip 2
|
C
|
2 | 98.15 | 56.47 | -81.40 | 581.39 | 66.0 | 2 | 66.0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.94 | 99.90 | 99.76 | 0.17 | 93.5 | 0 | 93.5 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.99 | 99.84 | 99.35 | 0.17 | 101.5 | 0 | 101.5 | 0/0 | 0 |
|
Chip 5
|
A
|
0 | 99.98 | 99.87 | 99.52 | 0.09 | 105.1 | 0 | 105.1 | 0/0 | 0 |
|
Chip 6
|
A
|
0 | 99.94 | 99.87 | 99.61 | 0.12 | 101.6 | 0 | 101.6 | 0/0 | 0 |
|
Chip 7
|
A
|
0 | 99.90 | 99.66 | 98.85 | 21.25 | 73.1 | 0 | 73.1 | 0/0 | 0 |
|
Chip 8
|
A
|
0 | 99.96 | 99.90 | 99.69 | 0.10 | 64.3 | 0 | 64.3 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.11 | 86.5 | 0 | 86.5 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.94 | 99.91 | 99.80 | 0.13 | 85.0 | 0 | 85.0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.95 | 99.90 | 99.73 | 0.09 | 73.6 | 0 | 73.6 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.95 | 99.91 | 99.78 | 0.09 | 75.6 | 0 | 75.6 | 0/0 | 0 |
|
Chip 13
|
A
|
2 | 99.91 | 99.84 | 99.61 | 2.01 | 49.4 | 2 | 49.4 | 0/0 | 0 |
|
Chip 14
|
C
|
1 | 19.87 | -1150.13 | -1.00 | 122.40 | 21.8 | 1 | 21.8 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.58 | -1.00 | 0.03 | 22.3 | 0 | 22.3 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
