Test Date: 2016-01-25 10:57
Analysis date: 2016-05-25 08:10
Analysis date: 2016-05-25 08:10
M-B-3-32 XRayHRQualification
Summary
| Module | Module | M-B-3-32 | |
| Grade | Grade | C | |
| ManualGrade | Manual Grade | None | |
| ROCGrades | ROC Grades A/B/C | 15/0/1 | |
| PixelDefects | Total Pixel Defects | 3 | |
| BumpBondingDefects | Bump Bonding Defects | 3 | |
| NoisyPixels | Noisy Pixels | 0 | |
| HotPixelDefects | Hot Pixels | 0 | |
| ROCsWithReadoutProblems | ROCs with r/o problems | 0 | |
| ROCsWithUniformityProblems | ROCs with unif problems | 1 | |
| Efficiency | Efficiency 20/50/80 | 99.95/99.77/99.53 | % |
| Noise | Mean Noise | -1 | e- |
Summary ROCs
| ROC | Grade | Defects | Eff 20 | Eff 50 | Eff 80 | Eff chi2 | Rate "60" | Rate "130" | BB def | RO prob | Unif. prob |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
Chip 0
|
A
|
0 | 99.96 | 99.88 | 99.61 | 0.12 | 51.1 | 104.0 | 0 | 0/0 | 0 |
|
Chip 1
|
A
|
0 | 99.84 | 99.51 | 98.41 | 11.44 | 33.9 | 69.1 | 0 | 0/0 | 0 |
|
Chip 2
|
A
|
0 | 99.95 | 99.85 | 99.53 | 0.13 | 56.1 | 114.4 | 0 | 0/0 | 0 |
|
Chip 3
|
A
|
0 | 99.95 | 99.86 | 99.56 | 0.14 | 83.2 | 168.9 | 0 | 0/0 | 0 |
|
Chip 4
|
A
|
0 | 99.96 | 99.90 | 99.71 | 0.17 | 87.2 | 177.1 | 0 | 0/0 | 0 |
|
Chip 5
|
A
|
1 | 99.94 | 99.89 | 99.70 | 0.17 | 93.1 | 189.0 | 1 | 0/0 | 0 |
|
Chip 6
|
A
|
2 | 99.95 | 99.90 | 99.73 | 0.10 | 90.9 | 184.8 | 2 | 0/0 | 0 |
|
Chip 7
|
C
|
0 | 99.96 | 99.87 | 99.59 | 0.23 | 73.5 | 144.6 | 0 | 0/0 | 2 |
|
Chip 8
|
A
|
0 | 99.96 | 99.89 | 99.67 | 0.10 | 64.7 | 132.1 | 0 | 0/0 | 0 |
|
Chip 9
|
A
|
0 | 99.95 | 99.86 | 99.57 | 0.13 | 74.5 | 151.7 | 0 | 0/0 | 0 |
|
Chip 10
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.07 | 73.1 | 148.9 | 0 | 0/0 | 0 |
|
Chip 11
|
A
|
0 | 99.97 | 99.84 | 99.43 | 0.89 | 62.4 | 127.3 | 0 | 0/0 | 0 |
|
Chip 12
|
A
|
0 | 99.96 | 99.88 | 99.60 | 0.14 | 69.1 | 140.6 | 0 | 0/0 | 0 |
|
Chip 13
|
A
|
0 | 99.96 | 99.88 | 99.62 | 0.10 | 42.7 | 87.3 | 0 | 0/0 | 0 |
|
Chip 14
|
A
|
0 | 99.93 | 99.04 | -1.00 | 0.03 | 19.1 | 39.3 | 0 | 0/0 | 0 |
|
Chip 15
|
A
|
0 | 99.96 | 99.45 | -1.00 | 0.03 | 20.5 | 42.0 | 0 | 0/0 | 0 |
Errors
| nCriticals | # Criticals | 0 | |
| nErrors | # Errors | 0 | |
| nWarnings | # Warnings | 0 | |
| channel_0_count | Channel 0 | 0 | |
| channel_1_count | Channel 1 | 0 | |
| channel_2_count | Channel 2 | 0 | |
| channel_3_count | Channel 3 | 0 | |
| message_tokenchain_count | Token Chain Length | 0 | |
| message_eventid_count | Event ID mismatch | 0 | |
| message_readback_count | Readback start marker | 0 | |
| message_notokenpass_count | has NoTokenPass | 0 | |
| message_datasize_count | Data size criticals | 0 | |
| message_missingevents_count | Missing Event criticals | 0 | |
| message_usbtimeout_count | USB criticals | 0 | |
| message_deser400_count | DESER400 failure | 0 | |
| message_daqerror_count | DAQ error | 0 |
Logfile
MoReWeb-v0.5.1-895-gd4c3d74 on branch master
