P_2x4T_079

P_2x4T_079_A

Parts committed by Arndt Kirk on date 12/11/2006

Part	ID
BBM	BBM_079-2x4T
VHDI	2x4_276

ROC ROC wafer Label

ROC0 W13_XX4JPAT 27D

ROC1 W13_XX4JPAT 27A

ROC2 W13_XX4JPAT 26D

ROC3 W13_XX4JPAT 26C

ROC4 W13_XX4JPAT 12A

ROC5 W13_XX4JPAT 12B

ROC6 W13_XX4JPAT 12C

ROC7 W13_XX4JPAT 12D

ROC	ROC wafer	Label
ROC0	W13_XX4JPAT	27D
ROC1	W13_XX4JPAT	27A
ROC2	W13_XX4JPAT	26D
ROC3	W13_XX4JPAT	26C
ROC4	W13_XX4JPAT	12A
ROC5	W13_XX4JPAT	12B
ROC6	W13_XX4JPAT	12C
ROC7	W13_XX4JPAT	12D

Inspected by Lockwood Gale on date 12/13/2006

LR_dev 0.053

LL_dev 0.067

FINAL COMMENT by Lockwood Gale No assembly problems. No problem wirebonding.

PLAQUETTE made READY for testing on 12/13/2006 by Lockwood Gale

P_2x4T_079_Aon 12/14/2006 10:31 AM

PLAQUETTE TESTED on 2006-12-14 by Petra Merkel

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 44 V

Operational Voltage 84 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7
Ibias_DAC	127	144	130	131	146	143	129	142
Vana	113	125	135	132	144	117	133	137
Cal_Del	93	73	85	72	77	79	77	81
Vthrs_Comp	62	81	66	75	85	71	69	78
Unbumped	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-12-18

Plaquette assigned to panel P4R_012
