In-plane thermal conductivity measurement
Experimentalist, Michael Wasem
Date of measurement, 5/29/2023
Apparatus, InPlane
Material, INPL22
Sample, 4
Length (mm), 19, 0.05
Width (mm), 50, 0.05
Thickness (mm), 4.11, 0.05
Heater Voltage, 15.02
Cooler Voltage, 0
Hot Fluxmeter Channels, 105, 106, 107, 108, 109, 110
Cold Fluxmeter Channels, 125, 126, 127, 128, 129, 130
Hot Fluxmeter Temperatures (C), 27.0832, 26.1257, 25.4069, 24.5315, 23.7187, 22.7628
Cold Fluxmeter Temperatures (C), 12.2056, 11.3223, 10.4836, 9.66303, 8.82369, 7.89019
Hot Fluxmeter Temperature Uncertainties (C), 0.00129746, 0.0014177, 0.00140551, 0.00144204, 0.00133174, 0.00146402
Cold Fluxmeter Temperature Uncertainties (C), 0.00120232, 0.000934569, 0.00107091, 0.0011764, 0.000913578, 0.00111172
Hot Fluxmeter Temperatures Relative to Hottest Thermistor (C), 0, -0.957077, -1.67664, -2.55006, -3.36341, -4.31858
Cold Fluxmeter Temperatures Relative to Hottest Thermistor (C), 0, -0.883508, -1.72207, -2.54278, -3.38256, -4.31563
Hot Fluxmeter Temperature Relative to Hottest Thermistor Uncertainties (C), 0, 0.00213222, 0.00187464, 0.00207365, 0.00196312, 0.00188309
Cold Fluxmeter Temperature Relative to Hottest Thermistor Uncertainties (C), 0, 0.0020353, 0.00116645, 0.00194166, 0.00150938, 0.00151486

Heater Thermistors	Cooler Thermistors
Heater Thermistors relative to hottest thermistor	Cooler Thermistors relative to the hottest thermistor

Analyst, Michael Wasem
Analysis date, 7/18/2023
Apparatus inter-thermistor distance (mm), 8
Apparatus thermistor bore diameter (mm), 1.27
Apparatus fluxmeter width (mm), 50.8
Apparatus fluxmeter thickness (mm), 6.36
Apparatus fluxmeter conductivity (W/mK), 355
Heater Biases: 0, 0, 0, 0, 0, 0
Cooler Biases: 0, 0, 0, 0, 0, 0
Hot fluxmeter flux (W/m^2), 37683.9 +/- 1431.13
Cold fluxmeter flux (W/m^2), 37917 +/- 1439.27
Heat flux through sample (W/m^2), 37800.5 +/- 1021.51
Heat flow through sample (W), 12.2129 +/- 0.330039
Temperature at hot end of sample (C), 21.9646 +/- 0.216797
Temperature at cold end of sample (C), 13.0551 +/- 0.103404
deltaT (C), 8.90943 +/- 0.240195
R (K/W), 0.729511, 0.027847
RA (Km^2/W), 0.000149915, 6.00802e-06

Hot flux meter fit	Cold flux meter fit
Hot flux meter difference fit	Cold flux meter difference fit
