![[IMAGE] of](P_2x5_141_A_IV.jpg)
| IV_XML-File |
| Maximum Voltage 600 V |
![[IMAGE] of](P_2x5_141_A_LASER.jpg)
| LASER_XML-File |
| Depletion Voltage 50 V |
| Operational Voltage 90 V |
Parts committed by Bolla Gino on date 3/19/2007
| Part | ID |
|---|---|
| BBM | BBM_141-2x5 |
| VHDI | 2x5_398 |
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W36_XD4K3LT | 40A |
| ROC1 | W36_XD4K3LT | 58D |
| ROC2 | W36_XD4K3LT | 58B |
| ROC3 | W36_XD4K3LT | 57B |
| ROC4 | W36_XD4K3LT | 57A |
| ROC5 | W36_XD4K3LT | 73C |
| ROC6 | W36_XD4K3LT | 51C |
| ROC7 | W36_XD4K3LT | 74C |
| ROC8 | W36_XD4K3LT | 75A |
| ROC9 | W36_XD4K3LT | 75B |
Inspected by Lockwood Gale on date 3/22/2007
| LR_dev | 0.059 |
| LL_dev | 0.062 |
| FINAL COMMENT by Lockwood Gale | No assembly problems. No wirebond problems. |
PLAQUETTE made READY for ENCAPSULATION on 3/22/2007 by Lockwood Gale
PLAQUETTE encapsulated on 3/22/2007 by Ozhan Koybasi
PLAQUETTE made READY for testing on 3/22/2007 by Ozhan Koybasi
P_2x5_141_Aon 3/23/2007 12:56 PM
P_2x5_141_Aon 3/23/2007 12:56 PM
PLAQUETTE TESTED on 2007-03-23 by Isaac Childres
|
|
|||
|
|
| ROC | ROC0 | ROC1 | ROC2 | ROC3 | ROC4 | ROC5 | ROC6 | ROC7 | ROC8 | ROC9 | |
| Ibias_DAC | 142 | 136 | 150 | 138 | 138 | 150 | 124 | 138 | 142 | 142 | |
| Vana | 121 | 138 | 141 | 126 | 138 | 138 | 111 | 126 | 135 | 116 | |
| Cal_Del | 95 | 89 | 82 | 83 | 103 | 80 | 105 | 83 | 91 | 78 | |
| Vthrs_Comp | 73 | 82 | 75 | 74 | 75 | 80 | 49 | 77 | 86 | 62 | |
| Unbumped | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Dead | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Noisy | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Undecoded | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | 0 | |
| Total BAD | 0 | 0 | 0 | 1 | 0 | 0 | 0 | 0 | 0 | 0 |
| ASSEMBLY_XML-File | SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File |
![[IMAGE] of](P_2x5_141_A_Ibias-dac.jpg) |
I_BIAS_DAC_XML-File |
![[IMAGE] of](P_2x5_141_A_Vana.jpg) |
VANA_XML-File |
![[IMAGE] of](P_2x5_141_ADead-PixelAlivetest.jpg){kind=tracking} |
DEAD_XML-File |
![[IMAGE] of](P_2x5_141_ANoisy-Pixel-Alive.jpg){kind=tracking} |
NOISY_XML-File |
![[IMAGE] of](P_2x5_141_AUndecoded-PixelAlivetest.jpg){kind=tracking} |
UNDECODED_XML-File |
![[IMAGE] of](P_2x5_141_Ano-bump-light.jpg) |
LIGHT_XML-File |
EXTRA DACs for NOISE
| VHldDe | 155 | 115 | 100 | 145 | 90 | 110 | 125 | 110 | 105 | 130 |
| Vsf | 135 | 145 | 140 | 135 | 140 | 140 | 130 | 135 | 145 | 140 |
| VoffsetOp | 75 | 85 | 110 | 70 | 75 | 85 | 50 | 60 | 70 | 70 |
| VIbias_PH | 100 | 100 | 100 | 100 | 105 | 100 | 100 | 95 | 105 | 100 |
Noise MAP
![[IMAGE] of](P_2x5_141_A-580-noise.jpg)
Efficiency MAP
![[IMAGE] of](P_2x5_141_A-580-efficiency.jpg)
PLAQUETTE READY TO BE SHIPPED
