P_2x5_117

P_2x5_117_A

Parts committed by Bolla Gino on date 12/21/2006

Part	ID
BBM	BBM_117-2x5
VHDI	2x5_285

ROC ROC wafer Label

ROC0 W32_XA4K5NT 14B

ROC1 W32_XA4K5NT 14A

ROC2 W32_XA4K5NT 13D

ROC3 W32_XA4K5NT 13C

ROC4 W32_XA4K5NT 13A

ROC5 W31_X44K5UT 62C

ROC6 W31_X44K5UT 62D

ROC7 W31_X44K5UT 63A

ROC8 W31_X44K5UT 63B

ROC9 W31_X44K5UT 64C

ROC	ROC wafer	Label
ROC0	W32_XA4K5NT	14B
ROC1	W32_XA4K5NT	14A
ROC2	W32_XA4K5NT	13D
ROC3	W32_XA4K5NT	13C
ROC4	W32_XA4K5NT	13A
ROC5	W31_X44K5UT	62C
ROC6	W31_X44K5UT	62D
ROC7	W31_X44K5UT	63A
ROC8	W31_X44K5UT	63B
ROC9	W31_X44K5UT	64C

Inspected by Kirk Arndt on date 2007-01-09

LR_dev 0.046

LL_dev 0.057

FINAL COMMENT by Kirk Arndt No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 2007-01-09 by Kirk Arndt

PLAQUETTE TESTED on 2007-01-10 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 48 V

Operational Voltage 88 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	142	144	144	134	138	138	144	136	136	132
Vana	142	144	129	130	123	126	134	135	131	133
Cal_Del	70	59	67	78	84	85	72	91	84	78
Vthrs_Comp	81	92	84	72	73	77	86	76	81	85
Unbumped	0	0	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	1	0	0	0	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	1	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY TO BE SHIPPED

Shipped on date 2007-01-24

Plaquette assigned to panel P3R_009
