P_2x5_088

P_2x5_088_A

Parts committed by Bolla Gino on date 11/15/2006

Part	ID
BBM	BBM_088-2x5
VHDI	2x5_262

ROC ROC wafer Label

ROC0 W21_XA4KFIT 75B

ROC1 W21_XA4KFIT 75A

ROC2 W21_XA4KFIT 73D

ROC3 W21_XA4KFIT 73C

ROC4 W21_XA4KFIT 03B

ROC5 W21_XA4KFIT 58A

ROC6 W21_XA4KFIT 58C

ROC7 W21_XA4KFIT 58D

ROC8 W21_XA4KFIT 40A

ROC9 W21_XA4KFIT 40B

ROC	ROC wafer	Label
ROC0	W21_XA4KFIT	75B
ROC1	W21_XA4KFIT	75A
ROC2	W21_XA4KFIT	73D
ROC3	W21_XA4KFIT	73C
ROC4	W21_XA4KFIT	03B
ROC5	W21_XA4KFIT	58A
ROC6	W21_XA4KFIT	58C
ROC7	W21_XA4KFIT	58D
ROC8	W21_XA4KFIT	40A
ROC9	W21_XA4KFIT	40B

Inspected by Lockwood Gale on date 11/17/2006

LR_dev 0.020

LL_dev 0.020

FINAL COMMENT by Lockwood Gale No assembly problems. No wirebonding problems.

PLAQUETTE made READY for testing on 11/17/2006 by Lockwood Gale

P_2x5_088_Aon 11/17/2006 3:32 PM

PLAQUETTE TESTED on 2006-11-17 by Isaac Childres

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 52 V

Operational Voltage 92 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	143	140	135	142	132	149	143	148	137	142
Vana	127	126	127	121	124	118	129	140	113	127
Cal_Del	90	80	91	79	85	89	87	88	79	79
Vthrs_Comp	74	85	68	80	75	75	81	73	82	72
Unbumped	0	0	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-11-28

Plaquette assigned to panel P3L_008
