P_2x5_071

P_2x5_071_A

Parts committed by Bolla Gino on date CCYY-MM-DD

Part	ID
BBM	BBM_071-2x5
VHDI	2x5_203

ROC ROC wafer Label

ROC0 X14JP6T 26D

ROC1 X14JP6T 26B

ROC2 X14JP6T 26A

ROC3 X14JP6T 25C

ROC4 X14JP6T 25B

ROC5 X14JP6T 14A

ROC6 X14JP6T 14B

ROC7 X14JP6T 14C

ROC8 X14JP6T 14D

ROC9 X14JP6T 15A

ROC	ROC wafer	Label
ROC0	X14JP6T	26D
ROC1	X14JP6T	26B
ROC2	X14JP6T	26A
ROC3	X14JP6T	25C
ROC4	X14JP6T	25B
ROC5	X14JP6T	14A
ROC6	X14JP6T	14B
ROC7	X14JP6T	14C
ROC8	X14JP6T	14D
ROC9	X14JP6T	15A

Inspected by Arndt Kirk on date 2006-07-07

LR_dev 0.070

LL_dev 0.071

FINAL COMMENT by Arndt Kirk No problem assembly. No wirebonding problem

PLAQUETTE made READY for testing on 2006-07-07 by Arndt Kirk

PLAQUETTE TESTED on 2006-7-10 by Bolla Gino

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 55 V

Operational Voltage 95 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	157	158	159	156	161	160	161	158	161	167
Vana	111	113	121	126	127	116	125	112	124	128
Cal_Del	78	77	82	92	73	72	68	80	86	84
Vthrs_Comp	75	71	80	76	69	67	76	82	67	81
Unbumped	0	0	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-07-11

Plaquette assigned to panel P3R_028
