P_2x5_011

P_2x5_011_A

Parts committed by Bolla Gino on date CCYY-MM-DD

Part	ID
BBM	BBM_011-2x5
VHDI	2x5_209

ROC ROC wafer Label

ROC0 X14JP6T 64A

ROC1 X14JP6T 63B

ROC2 X14JP6T 62B

ROC3 X14JP6T 61C

ROC4 X14JP6T 61B

ROC5 X14JP6T 31A

ROC6 X14JP6T 31B

ROC7 X14JP6T 31C

ROC8 X14JP6T 31D

ROC9 X14JP6T 32A

ROC	ROC wafer	Label
ROC0	X14JP6T	64A
ROC1	X14JP6T	63B
ROC2	X14JP6T	62B
ROC3	X14JP6T	61C
ROC4	X14JP6T	61B
ROC5	X14JP6T	31A
ROC6	X14JP6T	31B
ROC7	X14JP6T	31C
ROC8	X14JP6T	31D
ROC9	X14JP6T	32A

Inspected by Arndt Kirk on date 2006-06-13

LR_dev 0.061

LL_dev 0.044

FINAL COMMENT by Arndt Kirk No problem assembly. No wirebonding problem

PLAQUETTE made READY for testing on 2006-06-13 by Arndt Kirk

PLAQUETTE TESTED on 2006-6-14 by Gino Bolla

IV_XML-File

Maximum Voltage 600 V

LASER_XML-File

Depletion Voltage 70 V

Operational Voltage 120 V

ROC	ROC0	ROC1	ROC2	ROC3	ROC4	ROC5	ROC6	ROC7	ROC8	ROC9
Ibias_DAC	174	158	156	171	162	155	174	158	174	165
Vana	141	120	145	146	146	115	129	123	142	134
Cal_Del	75	98	80	81	72	86	85	97	81	82
Vthrs_Comp	95	85	91	94	90	66	67	82	82	90
Unbumped	0	0	0	0	0	0	0	0	0	0
Dead	0	0	0	0	0	0	0	0	0	0
Noisy	0	0	0	0	0	0	0	0	0	0
Undecoded	0	0	0	0	0	0	0	0	0	0
Total BAD	0	0	0	0	0	0	0	0	0	0

ASSEMBLY_XML-File	SUMMARY_XML-File, and SUMMARY_PER_ROC_XML-File
	I_BIAS_DAC_XML-File
	VANA_XML-File
	DEAD_XML-File
	NOISY_XML-File
	UNDECODED_XML-File
	LIGHT_XML-File

PLAQUETTE READY FOR SHIPPING

Shipped on date 2006-06-21
