Sensor: S_2x4T_15, Data for leakage current measurement , and plot on overall it is a BAD sensor
| ROC | ROC wafer | Label |
|---|---|---|
| ROC0 | W21_XA4KFIT | 20D |
| ROC1 | W21_XA4KFIT | 20C |
| ROC2 | W21_XA4KFIT | 20B |
| ROC3 | W21_XA4KFIT | 20A |
| ROC4 | W21_XA4KFIT | 15C |
| ROC5 | W20_XP4K3AT | 47D |
| ROC6 | W20_XP4K3AT | 48A |
| ROC7 | W20_XP4K3AT | 48B |
| Ibias_DAC, Ibias_DAC Data | 136 | 138 | 129 | 140 | 140 | 138 | 135 | 144 |
| Vana, VanaData | 130 | 122 | 118 | 125 | 121 | 127 | 128 | 128 |
| CalDelData and plots | 76 | 73 | 91 | 93 | 73 | 86 | 97 | 94 |
| VthrCompData and plots | 66 | 76 | 67 | 70 | 78 | 74 | 82 | 69 |
